XYGATE Merged Audit

Reference Manual

Chapter 3. Configuring Filters and the FILTERS File

XYPRO Technology Corporation 58 Proprietary and Confidential

ALERTTOKENs

This is a list of the columns you wish to display from the audit

detail, audit session, installation, and product tables. These

will be displayed when a user selects a detailed view option in

EMS.

Note: You must build XYGATE products’ EMS tokens into your system EMS

Templates to be able to view the individual tokens.

Example 1 below shows an EMS alert. A message will be sent to the EMS collector

\PROD.$0. It will be marked CRITICAL. The message “XAC SCF-255 invoked” will be

displayed. along with the following information from the SQL Database: the login name

of the user invoking the command (SUBJECTLOGIN), the timestamp (RECORDLCT),

the originating system, the terminal used, the IP address, and the contents of the

AUDIT.RESULT field.

Example 1: Sample ACTION paragraph for an EMS alert

ACTIONCOLL_BEGIN

ACTION_BEGIN

ACTIONTYPE ALERT

ALERTTARGET \PROD.$0

ALERTSEVERITY NONCRITICAL

ALERTSTRING XAC SCF-255 invoked

ALERTTOKENSBEGIN

! BODY OF EMS MESSAGE:

AUDIT.SUBJECTLOGIN

AUDIT.RECORDLCT

AUDIT.TERMINAL

SESSION.IPADDRV46

AUDIT.RESULT

ALERTTOKENSEND

ACTION_END

ACTIONCOLL_END

IGNORE action is defined by ACTIONTYPE = IGNORE

The IGNORE action tells MOVERs to discard audit records that match the DATA

selection criteria rather than writing them to the XMA database.

If you wish to perform multiple ACTIONS, IGNORE must always be last. The MOVER

will stop processing the audit record, once it reaches IGNORE.

There are no parameters to configure for IGNOREs.

UDP SYSLOG alerts are defined by ACTIONTYPE = IPALERT

If you wish to generate SYSLOG (IPALERT) alerts, you must configure the following

PARAMETERS in the appropriate Filters:

IPALERT_ADDRESS Defines the TCP/IP address where XMA will send the

string meant for a SYSLOG. This keyword is required for

IPALERT actions.
