XYGATE Merged Audit
®
Reference Manual
Chapter 3. Configuring Filters and the FILTERS File
XYPRO Technology Corporation 75 Proprietary and Confidential
In Example 2 below, if the node name on which MOVER using this Filter is running
begins with the characters "\PROD", then write a message to EMS when event
matching the selection criteria are encountered. MOVERs running on other nodes that
use this Filter will not write a message to EMS. All the MOVERs, regardless of node,
will add “Priv action” to the USER_DATA column of the XMA database.
Example 2: How to send EMS alerts for event on some but not all nodes
ACTIONCOLL_BEGIN
#IF @NODE LIKE "^\\PROD.*"
ACTION_BEGIN
ACTIONTYPE ALERT
ALERTTARGET $0
ALERTSEVERITY CRITICAL
ALERTEMSEVENTNUMBER 1001
ALERTSTRING Log down to SUPER.SUPER
ALERTTOKENSBEGIN
AUDIT.OPERATION
AUDIT.OBJECTNAME
AUDIT.SUBJECTLOGIN
AUDIT.OUTCOME
ALERTTOKENSEND
MAXRECORDAGE 7200 ! 2 hours
ACTION_END
#ENDIF
ACTION_BEGIN
ACTIONTYPE SETDATA
AUDIT.USER_DATA XYGATE Priv action
ACTION_END
!= Add other desired ACTIONs here
ACTIONCOLL_END
3.6 Determine the TCP/IP Process for Email, IPALERT, SNMP
Alerts
3.6.1 Step 1. Submit a WHO command
To determine the TCP/IP process that will send the various ALERTs, first do a WHO
command at a TACL prompt:
\NSKIT06 $DATA08.XYPRO 8> who
Home terminal: $ZTN5.#PTJVU1J ?-
TACL process: \NSKIT06.$X9NH
Primary CPU: 2 (NSE-A) Backup CPU: 3 (NSE-A)
Default Segment File: $DATA08.#0001196
Pages allocated: 266 Pages Maximum: 1036
Bytes Used: 17072 (0%) Bytes Maximum: 2121728
Current volume: $DATA08.XYPRO
Saved volume: $DATA08.XYPRO
Userid: 142,4 Username: XYPRO.DEV Security: "GGGO"
Logon name: XYPRO.DEV
