Add RCU
Example
08xx,YYYY/MM/DD,HH:MM:SS.xxx, 00:00,Out-of-band,uid=user-name,
196,,[Config Command],,,Accept,
from=xxxx:xxxx:xxxx:xxxx:xxxx:xxxx:xxxx:xxxx,,Seq.=xxxxxxxxxx
+Command=Add RCU
++S/N=XXXXX,MCU=X,RCU=X,Controller ID=7,MCU Port=1A,RCU Port=1B
+0000010200000000 0000000000000000
+0123456789ABCDEF 0123456789ABCDEF 0123456789ABCDEF,(snip)
Detailed Information
DescriptionItem
The command nameCommand
The serial number of the remote storage systemS/N
The CU number of the local storage systemMCU
"Free" is output when CU Free is selected
The CU number of the remote storage systemRCU
"Free" is output when CU Free is selected
The controller ID of the remote storage systemController ID
7: XP7, 6: P9500, 5: XP24000/XP20000 Disk Array, 19: HUS VM
The port name of the local storage systemMCU Port
The port name of the remote storage systemRCU Port
Indicates the 16 byte parameter added in the storage system and the command
parameter in binary format
Command parameter
Add RCU Path
Example
08xx,YYYY/MM/DD,HH:MM:SS.xxx, 00:00,Out-of-band,uid=user-name,
196,,[Config Command],,,Accept,
from=xxxx:xxxx:xxxx:xxxx:xxxx:xxxx:xxxx:xxxx,,Seq.=xxxxxxxxxx
+Command=Add RCU Path
++S/N=XXXXX,MCU=X,RCU=X,MCU Port=1A,RCU Port=1B
+0000010200000000 0000000000000000
+0123456789ABCDEF 0123456789ABCDEF 0123456789ABCDEF,(snip)
Detailed Information
DescriptionItem
The command nameCommand
The serial number of the remote storage systemS/N
The CU number of the local storage systemMCU
"Free" is output when CU Free is selected
The CU number of the remote storage systemRCU
"Free" is output when CU Free is selected
The port name of the local storage system to be addedMCU Port
