Table 10 Supported Platforms: IPv4 vs IPv6 (continued)
RAID Manager / IPv6*IPv4
N/AAVAVN/AAVAVAVLinux
N/AAVAVN/AAVAVAVTru64
AVAVAVN/AAVAVAVOpenVMS
N/AAVAVN/AAVAVAVIRIX64
*See “About platforms supporting IPv6” (page 18).
Legend:
AV: Available for communicating with different platforms.
N/A: Not applicable (Windows LH does not support IPv4 mapped IPv6).
Minimum platform versions for RAID Manager/IPv6 support:
• HP-UX: HP-UX 11.23 (PA/IA) or later
• Solaris: Solaris 8/Sparc or later, Solaris 10/x86/64 or later
• AIX: AIX 5.1 or later
• Windows: Windows 2008(LH), Windows 2003 + IPv6 Install
• Linux: Linux Kernel 2.4 (RH8.0) or later
• Tru64: Tru64 v5.1A or later. Note that v5.1A does not support the getaddrinfo() function, so this must be specified
by IP address directly.
• OpenVMS: OpenVMS 8.3 or later
• UDP ports: Contact your network administrator for appropriate UDP port numbers to use in your network. The
network administrator must enable these ports to allow traffic between RAID Manager servers. If you define a
HORCM_MON IP address in your configuration definition file, the port defined in this entry must be enabled. For
details, see “Setting up UDP ports” (page 39).
Requirements and restrictions for z/Linux
In the following example, z/Linux defines the open volumes that are connected to FCP as /dev/sd*.
Also, the mainframe volumes (3390-xx) that are connected to FICON are defined as /dev/dasd*.
Figure 1 Example of a RAID Manager Configuration on z/Linux
Requirements and restrictions for z/Linux 13
