5. Execute the following command on the standby host.
When the OS used in a PowerHA environment is AIX V6.1 TL06 or AIX
V7.1 with no TL:
# clusterconf -r hdiskxx
When the OS used in a PowerHA environment is AIX V6.1 TL07 or later or
AIX V7.1 TL01 or later:
# clctrl -start -m node-name
6. Execute the following command on the standby host to start PowerHA.
# smitty cl_start
7. Execute the following command on the active host to stop PowerHA.
# smitty cl_stop
8. Execute the following command on the active host.
When the OS used in a PowerHA environment is AIX V6.1 TL06 or AIX
V7.1 with no TL:
# clcmd stopsrc -s clconfd
# clusterconf -fu
When the OS used in a PowerHA environment is AIX V6.1 TL07 or later or
AIX V7.1 TL01 or later:
# clctrl -stop -m node-name
9. Perform a new installation, upgrade installation, or re-installation of HDLM
on the active host.
When performing a new installation of HDLM in a local boot disk
environment:
Perform the procedure described in Stop Applications on page 3-37 of
Preparations for an Upgrade Installation or Re-installation of HDLM on
page 3-37.
When performing a new installation of HDLM in a boot disk environment:
Perform the procedure described in Perform Operations for HDLM
Management-Target Device on page 3-37 of Preparations for an
Upgrade Installation or Re-installation of HDLM on page 3-37.
When performing an upgrade installation or re-installation of HDLM in a
local boot disk environment:
Perform the procedure described in When Installing HDLM in a Local
Boot Disk Environment on page 3-38 of Performing an Upgrade
Installation or Re-installation of HDLM on page 3-38.
