HP XP P9000 Audit Log User and Reference Guide

DescriptionItem
ON: Execute Correction Copy, OFF: Do not execute Correction Copy(Correction Copy)
Indicates the setting status of Copy Operation (Dynamic Sparing).Copy Operation
ON: Execute Dynamic Sparing, OFF: Do not execute Dynamic Sparing(Dynamic Sparing)
The method to allocate the serial number reported by Read Configuration Data command.Read Configuration
Data Mode
ON: Method supporting 4096, OFF: Traditional compatible method
The threshold to report link failure.Link Failure Threshold
The LDKC number, the CU number, and the LDEV number.LDKC:CU: LDEV
Indicates the setting status of Destage.Destage
ON: Execute write through operation (report the completion of the writing to the host after the
writing to the disk drive has completed).
OFF: Do not execute write through operation (report the completion of the writing to the host
when the data is written in the cache memory).
The number of LDEVs.Num. of LDEVs
The LPR name.LPR
The level of Cache Tuning.Cache Tuning
The number of LPRs.Num. of LPRs
Command ControlCommand Control
The local mode number.Mode
The setting status.Set
ON: Set, Off: Release
The number of local modes.Num. of Modes
Setting executed from the debug window (Set: fix).Debug Mode
NOTE: Only the changed items will be output.
[Install] System Tuning
Example
07xx,YYYY/MM/DD,HH:MM:SS.xxx, 00:00,SVP,uid=user-name,1,,
[Install],System Tuning,,Normal end,
from=xxxx:xxxx:xxxx:xxxx:xxxx:xxxx:xxxx:xxxx,,Seq.=xxxxxxxxxx
+Serial No.=64040
+IP Address Mode=Based on Serial Number
+IP Address=126.132.246.15
+Subnet Mask=255.0.0.0
+{Port,CU Number,Emulation}=[{1E,-,I-2107},
{3E,0x00:0x10-0x00:0x1F,I-2107},{5E,-,I-2107},{7E,-,I-2107}],
Num. of Ports=4
+{LDKC:CU,LDEV,SSID}=[{0x00:0x00,0x00-0xff,0x0005}],
Num. of SSIDs=1+{TPF Enable,Number of MPLs}={ON,4096}
102 Audit log examples
