HP XP P9000 Audit Log User and Reference Guide

+{S/N,MCU LDKC,MCU,RCU LDKC,RCU,SSID,Controller ID}
={99999,0x00,0x3F,0x00,0x7F,0x0004,4}
++{MCU Port,RCU Port}
=[{1E,3E},{5E,7E},{1F,3F},{5F,7F},{1G,3G},
{5G,7G},{1H,3H}],Num. of Port Pairs=7
Detailed information
DescriptionItem
Indicates a serial number of the device.S/N
The LDKC number of the connected LDKC.MCU LDKC
The LDKC number of the paired LDKC.RCU LDKC
The path group ID. When the path group ID is default setting, “Default” is output.Path Gr.ID
The controller ID.Controller ID
The CU number of the connected CU.MCU
The CU number of the paired CU.RCU
The SSID.SSID
The port number of MCU.MCU Port
The port number of RCU.RCU Port
The number of port pairs set.Num. of Port Pairs
[RCU] Add RCU
Example 1: CU Free is used
07xx,YYYY/MM/DD,HH:MM:SS.xxx, 00:00,RMI AP,uid=user-name,1,,
[RCU],Add RCU,,Normal end,
from=xxxx:xxxx:xxxx:xxxx:xxxx:xxxx:xxxx:xxxx,,Seq.=xxxxxxxxxx
+{S/N,MCU LDKC,RCU LDKC,Path Gr.ID,Controller ID,Min.Path,
MIH Time(s),Round Trip Time(ms),FREEZE}
={99999,0x00,0x00,Default,4,08,015,001,Disable}
++{MCU Port,RCU Port}
=[{1E,3E},{5E,7E},{1F,3F},{5F,7F},{1G,3G},{5G,7G},{1H,3H},
{5H,7H}],Num. of Port Pairs=8
Example 2: CU Free is not used
07xx,YYYY/MM/DD,HH:MM:SS.xxx, 00:00,RMI AP,uid=user-name,1,,
[RCU],Add RCU,,Normal end,
from=xxxx:xxxx:xxxx:xxxx:xxxx:xxxx:xxxx:xxxx,,Seq.=xxxxxxxxxx
+{S/N,MCU LDKC,MCU,RCU LDKC,RCU,SSID,Controller ID,Min.Path,
MIH Time(s),Round Trip Time(ms),FREEZE}
={99999,0x00,0x3F,0x00,0x7F,0x0004,4,08,015,001,Disable}
++{MCU Port,RCU Port}
=[{1E,3E},{5E,7E},{1F,3F},{5F,7F},{1G,3G},
{5G,7G},{1H,3H},{5H,7H}],Num. of Port Pairs=8
Detailed information
DescriptionItem
Indicates a serial number of the registered RCU device.S/N
The LDKC number of the connected LDKC.MCU LDKC
The LDKC number of the paired LDKC.RCU LDKC
170 Audit log examples
