HP XP P9000 Audit Log User and Reference Guide

DescriptionItem
Indicates SSID of the RCU where the optional setting is changed.SSID
The minimum number of paths after change.Min.Path
The value of RIO MIH (Remote I/O Missing Interrupt Handler) timer (wait time until data copy
from MCU to RCU is completed). The unit represents seconds.
MIH Time(s)
The round-trip response time (delay time for round-trip remote I/O) after change. The unit is in
milliseconds. This value is output when Continuous Access Synchronous or Continuous Access
Synchronous Z is used.
Round Trip Time(ms)
Indicates whether CGROUP (FREEZE/RUN) PPRC TSO command support is enabled or disabled.
This value is output only when Continuous Access Synchronous Z is used.
FREEZE
Enable or Disable is output.
[RCU] Delete Path
Example 1: CU Free is used
07xx,YYYY/MM/DD,HH:MM:SS.xxx, 00:00,RMI AP,uid=user-name,1,,
[RCU],Delete Path,,Normal end,
from=xxxx:xxxx:xxxx:xxxx:xxxx:xxxx:xxxx:xxxx,,Seq.=xxxxxxxxxx
+{S/N,MCU LDKC,RCU LDKC,Path Gr.ID,Controller ID}
={99999,0x00,0x00,Default,4}
++{MCU Port,RCU Port}=[{1E,3E},{5E,7E},{1F,3F},{5F,7F},
{1G,3G},{5G,7G},{1H,3H}],Num. of Port Pairs=7
Example 2: CU Free is not used
07xx,YYYY/MM/DD,HH:MM:SS.xxx, 00:00,RMI AP,uid=user-name,1,,
[RCU],Delete Path,,Normal end,
from=xxxx:xxxx:xxxx:xxxx:xxxx:xxxx:xxxx:xxxx,,Seq.=xxxxxxxxxx
+{S/N,MCU LDKC,MCU,RCU LDKC,RCU,SSID,Controller ID}
={99999,0x00,0x3F,0x00,0x7F,0x0004,5}
++{MCU Port,RCU Port}=[{1E,3E},{5E,7E},{1F,3F},{5F,7F},
{1G,3G},{5G,7G},{1H,3H}],Num. of Port Pairs=7
Detailed information
DescriptionItem
The serial number of the device of RCU where the path has been deleted.S/N
The LDKC number of the connected LDKC.MCU LDKC
The LDKC number of the paired LDKC.RCU LDKC
The path group ID of the path deleted. When the path group is a default setting, “Default” is
output.
Path Gr.ID
The controller ID of the RCU where the path has been deleted.Controller ID
The CU number of the connected CU.MCU
The CU number of the paired CU.RCU
Indicates SSID.SSID
The port number of MCU.MCU Port
The port number of RCU.RCU Port
The number of path pairs deleted.Num. of Port Pairs
172 Audit log examples
