Detailed information
DescriptionItem
The LDKC, CU, and LDEV numbers of the volume specified to the main volume when the
pair is created.
M-VOL(LDKC:CU:LDEV)
The LDEV number of the volume specified to the remote volume when the pair is created.R-VOL(LDEV)
The serial number of the device.S/N
The LDKC number of the paired LDKC.LDKC
Indicates the SSID of the RCU.SSID
The controller ID of the RCU.Controller ID
The update copy mode setting; Sync: Synchronous modeType
The initial copy mode setting; Entire: Copy all, None: Do not copy.Initial Copy
The fence level setting (the condition that MCU rejects the write operation to the main
volume.) Never: No condition, Data: S-VOL data, Status: S-VOL status.
Fence Level
The initial copy speed setting (the number of tracks you can copy at a time).Copy Pace
The priority of the initial copy operation setting (scheduling order).Priority
The unit of the differential management setting: Auto, Cylinder, Track.Diff
Indicates whether the setting to copy the CFW data to the remote volume is enabled or
not. Only M-VOL: Copy to main volume only is enabled Copy to R-VOL: Copy to main and
remote volume is enabled.
CFW
Indicates whether DFW use to the remote volume is set or not.DFW
Not Required: DFW not required, Required: DFW required
Indicates whether or not the host I/O time stamp is transferred to R-VOL when the pair is
created.
TS
Enable: transferred, Disable: not transferred
The result of operation.Result
Normal end: Normal end, Error (xxxx-yyyyy): Abnormal end
xxxx: Part code, yyyyy: Error code
The number of created pairs.Num. of Pairs
[Cnt Ac-S Z] Change Option
Example
07xx,YYYY/MM/DD,HH:MM:SS.xxx, 00:00,RMI AP,uid=user-name,1,,
[Cnt Ac-S Z],Change Option,,Normal end,
from=xxxx:xxxx:xxxx:xxxx:xxxx:xxxx:xxxx:xxxx,,Seq.=xxxxxxxxxx
+{Max Initial Copy,CU Activity,Path Blockade Watch(s),
Path Blockade SIM Watch(s),Service SIM}={128,Enable,45,070,
Not Report}
+{LDKC,CU,Service SIM,PPRC Support,SCP Time(s),Max Initial Copy}
=[{0x00,0x00,Not Report,Yes,518400,04},
{0x00,0x01,Not Report,Yes,518400,04},
{0x00,0x02,Not Report,Yes,518400,04},
{0x00,0x03,Not Report,Yes,518400,04},
{0x00,0x04,Not Report,Yes,518400,04},(snip)-(snip)],
Num. of CUs=255
