HP XP P9000 Audit Log User and Reference Guide

DescriptionItem
The serial number of the logical device (storage system).S/N
The controller ID.CTRLID
The priority of copy.Priority
The consistency group ID.CTG
Indicates whether initial copy or paircreate operation for Delta resync is executed or
not.
Initial Copy
Entire: execute initial copy, None: do not execute initial copy, Delta: execute paircreate
operation for Delta resync
The master journal number.M-JNL
The restore journal number.R-JNL
The path group ID specified for the storage systemPath Gr. ID
When the path group ID is default setting, "Default" is output.
The error level; Mirror: Mirror level, LU: LU levelError Level
The result of operationResult
Normal end: Normal end,
Error(xxxx-yyyyy): Abnormal end
where xxxx: Part code, yyyyy: Error code
The number of pairs.Num. of Pairs
[Cnt Ac-J] Pairresync
Example
07xx,YYYY/MM/DD,HH:MM:SS.xxx, 00:00,RMI AP,uid=user-name,1,,
[Cnt Ac-J],Pairresync,,Normal end,
from=xxxx:xxxx:xxxx:xxxx:xxxx:xxxx:xxxx:xxxx,,Seq.=xxxxxxxxxx
+{P-VOL(Port-G-ID-LUN),S-VOL(Port-G-ID-LUN),MirrorID,S/N,CTRLID,
Priority,CTG,Range,M-JNL,R-JNL,Error Level,Resync Mode,Result}
=[{4C-0x00-0x000,4A-0x00-0x000,0x00,67676,6,32,0x000,LU,0x001,
0x001,Mirror,Normal,Normal end},{4C-0x00-0x001,4A-0x00-0x001,
0x00,67676,6,32,0x000,LU,0x001,0x001,Mirror,Normal,Normal end}],
Num. of Pairs=2
Detailed information
DescriptionItem
The port number, host group number, and LUN of the primary data volume.P-VOL(Port-G-ID-LUN)
The port number, host group number, and LUN of the secondary data volume.S-VOL(Port-G-ID-LUN)
The mirror ID.MirrorID
The serial number of the logical device (storage system).S/N
The controller ID.CTRLID
The priority of copy.Priority
The consistency group ID.CTG
The range to restore the pair.Range
Mirror: Mirror range. LU: LU range
204 Audit log examples
