HP XP P9000 Audit Log User and Reference Guide

DescriptionItem
The master journal number.M-JNL
The restore journal number.R-JNL
The error level.Error Level
Mirror: Mirror level, LU: LU level
Indicates the Resync Mode.Normal: normal resync, Delta: delta resync, Return to standby:
return to standby status
Resync Mode
The result of operation.Result
Normal end: Normal end, Error (xxxx-yyyyy): Abnormal end
xxxx: Part code, yyyyy: Error code
The number of pairs.Num. of Pairs
[Cnt Ac-J] Pairsplit-r
Example
07xx,YYYY/MM/DD,HH:MM:SS.xxx, 00:00,RMI AP,uid=user-name,1,,
[Cnt Ac-J],Pairsplit-r,,Normal end,
from=xxxx:xxxx:xxxx:xxxx:xxxx:xxxx:xxxx:xxxx,,Seq.=xxxxxxxxxx
+{P-VOL(Port-G-ID-LUN),S-VOL(Port-G-ID-LUN),MirrorID,S/N,CTRLID,
Type,S-VOL Write,Range,Suspend Mode,Result}
=[{4C-0x00-0x000,4A-0x00-0x000,0x00,67676,6,P-VOL,
Disable,LU,Flush,Normal end},
{4C-0x00-0x001,4A-0x00-0x001,0x00,67676,6,P-VOL,Disable,LU,
Flush,Normal end}],Num. of Pairs=2
Detailed information
DescriptionItem
The port number, host group number, and LUN of the primary data volume.P-VOL(Port-G-ID-LUN)
The port number, host group number, and LUN of the secondary data volume.S-VOL(Port-G-ID-LUN)
The mirror ID.MirrorID
The serial number of the logical device (storage system).S/N
The controller ID.CTRLID
Indicates whether the split data volume is a primary or secondary data volume.Type
P-VOL: Primary, S-VOL: Secondary
Indicates whether writing to the secondary volume is enabled.S-VOL Write
Disable: Disabled, Enable: Enabled
The split range.Range
LU: LU range, Mirror: Mirror range
The suspend mode. Purge: Purge mode, Flush: Flush modeSuspend Mode
The result of operation.Result
Normal end: Normal end, Error (xxxx-yyyyy): Abnormal end
xxxx: Part code, yyyyy: Error code
The number of pairs.Num. of Pairs
Continuous Access Journal descriptions 205
