Detailed information
DescriptionItem
The name of the vendor of the external storage system that the mapped external volume exists.Vendor
The product name of the external storage system that the mapped external volume exists.Product
The serial number the external storage system that the mapped external volume exists.Serial
The identification character 1 of the mapped external volume.VolumeID1
The identification character 2 of the mapped external volume.VolumeID2
The device name that the mapped external volume notifies to the host.Device
The capacity of the mapped external volume indicated by blocks.Capa(blocks)
The number of the external volume group and the reference number assigned to the external
volume of the mapped external volume. The number on the left of a dash (-) is the external
volume number and the number on the right of the dash (-) is the reference number of the group.
ExGroup
The path group number of the mapped external volume.PathGroup
The CLPR number of the mapped external volume.CLPR
The emulation type of the mapped external volume.Emulation
The cache mode of the mapped external volume.Cache
Enable: Enabled, Disable: Disabled
The inflow control setting of the cache of the mapped external volume.Inflow
Enable: Enabled, Disable: Disabled
MP Blade ID specified for the external volume.MP Blade ID
When a MP Blade ID is specified automatically, “Auto” is output.
The load balance mode of the mapped external volumeLoadBalanceMode
Normal Round-robin, Extended Round-robin, or Disable will appear.
If the alternative path mode is Single, a hyphen (-) is displayed.
The result of the operation.Result
Normal end: Normal end, Error (xxxx-yyyyy): Abnormal end
xxxx: Part code, yyyyy: Error code
The port name of the external port of the local storage system.Port
The WWN of the Target port of the external storage system.WWN
The LUN of the external volume.LUN
The number of mapping path (Port-WWN-LUN) configured.Num. of Paths
The result of attempting to create an external path.PathResult
If the path is created normally, the audit log includes the following: PathResult: Normal end.
If the path is not created, the audit log includes this: PathResult: Error(xxxx-yyyy): Abnormal
end, where xxxx is the part code and yyyy is the error code.
The LDKC number, CU, and LDEV number of the LDEVs in the mapped external volume. The
number on the left of the colon is an LDKC number, the number between the colons is a CU
number, and the number on the right of the colon is an LDEV number
LDKC:CU:LDEV
The capacity of LDEVs in the mapped external volumes indicated by blocks.LDEVCapa(blocks)
The SSID.SSID
MP Blade ID specified for the LDEV.LDEV MP Blade ID
