HP XP P9000 Audit Log User and Reference Guide

[Auto LUN] Delete Auto Plan
Example
07xx,YYYY/MM/DD,HH:MM:SS.xxx, 00:00,RMI AP,uid=user-name,1,,
[Auto LUN],Delete Auto Plan,,Normal end,
from=xxxx:xxxx:xxxx:xxxx:xxxx:xxxx:xxxx:xxxx,,Seq.=xxxxxxxxxx
+{PlanNo}=[{1}],Num. of Plan = 1
Detailed information
DescriptionItem
The executed operation.PlanNo
Number: is output when a part of the auto migration plans is deleted. The number indicates
what number of lines from the top of the auto migration plan list and the subsequent lines were
deleted.
ALL: is output when all the auto migration plans are deleted.
The number of settings. 1 is always output.Num. of Plan
[Auto LUN] Del Migration Log
Example
07xx,YYYY/MM/DD,HH:MM:SS.xxx, 00:00,RMI AP,uid=user-name,1,,
[Auto LUN],Del Migration Log,,Normal end,
from=xxxx:xxxx:xxxx:xxxx:xxxx:xxxx:xxxx:xxxx,,Seq.=xxxxxxxxxx
[Auto LUN] Set Auto Plan Param
Example
07xx,YYYY/MM/DD,HH:MM:SS.xxx, 00:00,RMI AP,uid=user-name,1,,
[Auto LUN],Set Auto Plan Param,,Normal end,
from=xxxx:xxxx:xxxx:xxxx:xxxx:xxxx:xxxx:xxxx,,Seq.=xxxxxxxxxx
+{SetType,PlanSwitch,PlanType,PlanDay,MonitorPeriod,SampleCount}
=[{Customize,Disable,Every day,,06:00-02:00,All}],Num. of Data = 1
Detailed information
DescriptionItem
The executed operation.SetType
Default: The default auto migration plan is applied (click Default, and then click Set).
Customize: The customized auto migration plan is applied (click Set after changing the value
of the auto migration plan parameter).
Indicates whether the auto migration plan settings are enabled or disabled.PlanSwitch
Disable or Enable is output.
The specified sampling term.PlanType
One of these values is output:
• None
• Every day
• Once every X days (For the value of X, see PlanDay index below)
• Once a week
• Once a month
226 Audit log examples
