HP XP P9000 Audit Log User and Reference Guide

DescriptionItem
Default: The default auto migration plan is applied (click Default, and then click Set).
Customize: The customized auto migration plan is applied (click Set after changing the
value of the auto migration plan parameter).
The specified start time of the auto migration, that is, the time when the auto migration
plan execution starts.
StartTime
The specified upper limit of the migration time.TimeRequiredMax(min.)
The upper limit of the migration time is displayed by the number from 10 to 120. The unit
is minute.
The specified upper limit of the disk usage rate.AvailabilityMax(%)
The upper limit of the disk usage rate is displayed by the number from 10 to 100. The
unit is percent (%).
The specified maximum number of the volumes that are migrated in a same time.VolulmeMax
The maximum number of the volumes that are migrated in a same time is displayed by
the number from 1 to 40.
The number of settings. 1 is always output.Num. of Data
[Auto LUN] Set Reserved Vol
Example
07xx,YYYY/MM/DD,HH:MM:SS.xxx, 00:00,RMI AP,uid=user-name,1,,
[Auto LUN],Set Reserved Vol,,Normal end,
from=xxxx:xxxx:xxxx:xxxx:xxxx:xxxx:xxxx:xxxx,,Seq.=xxxxxxxxxx
+{Set,LDKC:CU:LDEV,OwnerID,Result}
=[{Reserved,0x00:0x00:0x00,00,Normal end},
{Reserved,0x00:0x00:0x01,00,Normal end},
{Reserved,0x00:0x00:0x02,00,Normal end},
{Reserved,0x00:0x00:0x03,00,Normal end},
{Reserved,0x00:0x00:0x04,00,Normal end},
{Reserved,0x00:0x00:0x05,00,Normal end},
{Reserved,0x00:0x00:0x06,00,Normal end}] Num. of LDEVs = 7
Detailed information
DescriptionItem
The operation executed to the logical volume.Set
Normal: Set to the normal volume
Reserved: Set to the reserved volume of Auto LUN
The ID of the logical volume which the setting is changed. The number on the left of the colon
is an LDKC number, the number between the colons is a CU number, and the number on the
right of the colon is an LDEV number.
LDKC:CU:LDEV
The application that sets this reserved volume of Auto LUN.OwnerID
When a reserved volume of Auto LUN is set from the Attribute window, "00" is output. For a
reserved volume of Auto LUN set by another application, the ID of the application is output.
The result of operation.Result
Normal end: Normal end, Error (xxxx-yyyyy): Abnormal end
xxxx: Part code, yyyyy: Error code
The number of logical volumes which the setting is changed.Num. of LDEVs
Auto LUN descriptions 229
