[ESAM] Pairsplit-r
Example
07xx,YYYY/MM/DD,HH:MM:SS.xxx, 00:00,RMI AP,uid=user-name,1,,
[ESAM],Pairsplit-r,,Normal end,
from=xxxx:xxxx:xxxx:xxxx:xxxx:xxxx:xxxx:xxxx,,Seq.=xxxxxxxxxx
+{P-VOL(Port-G-ID-LUN),S-VOL(Port-G-ID-LUN),Type,S-VOL Write,Kind,
Result}
=[{1A-0x00-0x000,1B-0x00-0x000,P-VOL,Disable,S-VOL,Normal end},
{1A-0x00-0x001,1B-0x00-0x001,P-VOL,Disable,S-VOL,Normal end},
(snip)-(snip)],Num. of Pairs=xx
Detailed information
DescriptionItem
The port number, host group number, and LUN of the primary volume in the split pair
sequentially.
P-VOL(Port-G-ID-LUN)
The port number, host group number, and LUN of the secondary volume in the split pair
sequentially.
S-VOL(Port-G-ID-LUN)
The volume type of the volume on the primary site.Type
P-VOL: Primary volume, S-VOL: Secondary volume
Indicates whether writing to the secondary volume is enabled.S-VOL Write
Enable: Writing is enabled
Disable: Writing is disabled
The suspend type set.Kind
P-VOL Failure: Writing to the P-VOL is disabled
S-VOL: Writing to the P-VOL is enabled
The result of the operation.Result
Normal end: Normal end, Error (xxxx-yyyyy):
Abnormal end xxxx: Part code, yyyyy: Error code
The number of split pairs.Num. of Pairs
[ESAM] Pairsplit-S
Example
07xx,YYYY/MM/DD,HH:MM:SS.xxx, 00:00,RMI AP,uid=user-name,1,,
[ESAM],Pairsplit-S,,Normal end,
from=xxxx:xxxx:xxxx:xxxx:xxxx:xxxx:xxxx:xxxx,,Seq.=xxxxxxxxxx
+{P-VOL(Port-G-ID-LUN),S-VOL(Port-G-ID-LUN),Type,Force,Result}
=[{1A-0x00-0x000,1B-0x00-0x000,P-VOL,No,Normal end},
{1A-0x00-0x001,1B-0x00-0x001,P-VOL,No,Normal end},
+{1A-0x00-0x002,1B-0x00-0x002,P-VOL,No,Normal end},
(snip)-(snip)],Num. of Pairs=xx
Detailed information
DescriptionItem
The port number, host group number, and LUN of the primary volume in the deleted pair
sequentially.
P-VOL(Port-G-ID-LUN)
The port number, host group number, and LUN of the secondary volume in the deleted
pair sequentially.
S-VOL(Port-G-ID-LUN)
