Num. of Ports=8
+Num. of CHAs=4
Detailed information for example 1
DescriptionItem
The channel adapter (CHA) mounting location.CHA
The kind of PCB mounted.Kind
The mounting location of the port.Port
The type of Initiator or Target.Initiator/Target
The channel speed is indicated for open systems.Channel Speed
1: 1 Gbps, 2: 2 Gbps, 4: 4 Gbps, 8: 8 Gbps, 10: 10 Gbps, Auto: Auto mode.
Indicates the range of the CU number that the port belongs.CU Number
The number of ports.Num. of Ports
The HTP or FNP is indicated for FICON.HTP/FNP
The emulation type is indicated for mainframe systems.Emulation
The number of Channel Adaptors (CHA)s.Num. of CHAs
Example 2: installing additional subsystems, DKAs, ECC Groups or LDEVs
07xx,YYYY/MM/DD,HH:MM:SS.xxx, 00:00,SVP,uid=user-name,1,,
[Install],Install,,Normal end,
from=xxxx:xxxx:xxxx:xxxx:xxxx:xxxx:xxxx:xxxx,,Seq.=xxxxxxxxxx
+{DKA,Kind}=[{DKA-1AL,DKF 4MP},{DKA-1LL,DKF 4MP},
{DKA-2ML,DKF 4MP},{DKA-2XL,DKF 4MP}],Num. of DKAs=4
+{DKU,Kind}=[{DKU-11,2.5" DKU}],Num. of DKUs=1
+{PG,RAID Level,Drive Type,Protection Level,Emulation,
Concatenation,Encryption}
={3-1,RAID1 (2D+2D),DKR5C-J600SS,Standard,OPEN-V,-,Disable},
++{LDKC:CU:LDEV,Emulation,Size,Unit,System Disk,SSID,MPB}
=[{0x00:0x05:0x00,OPEN-V,2251536384,LBA,Disable,0x0009,Auto}],
Num. of LDEVs=1
+{PG,RAID Level,Drive Type,Protection Level,
Emulation,Concatenation,Encryption}
={3-2,RAID5 (3D+1P),DKR5C-J600SS,Standard,OPEN-V,-,Disable},
++{LDKC:CU:LDEV,Emulation,Size,Unit,System Disk,SSID,MPB}
=[{0x00:0x05:0x01,OPEN-V,3377304576,LBA,Disable,0x0009,Auto}],
Num. of LDEVs=1
+{PG,RAID Level,Drive Type,Protection Level,
Emulation,Concatenation,Encryption}
={3-3,RAID1 (2D+2D),DKR5C-J600SS,Standard,OPEN-V,-,Disable},
++{LDKC:CU:LDEV,Emulation,Size,Unit,System Disk,SSID,MPB}
=[{0x00:0x05:0x02,OPEN-V,2251536384,LBA,Disable,0x0009,Auto}],
Num. of LDEVs=1
+Num. of PGs=3
+{B4,SPARE,Drive Type}=[{3,1,DKR5C-J600SS}],Num. of SPAREs=1
This logged information indicates that the formatting was only requested but not completed. If the
operation does not require the formatting, this logged information indicates that the volume was
created.
