HP XP P9000 Audit Log User and Reference Guide

[Install] Set Fibre Topology
Example
07xx,YYYY/MM/DD,HH:MM:SS.xxx, 00:00,SVP,uid=user-name,1,,
[Install],Set Fibre Topology,,Normal end,
from=xxxx:xxxx:xxxx:xxxx:xxxx:xxxx:xxxx:xxxx,,Seq.=xxxxxxxxxx
+{Port,Fabric,Connection}
=[{XX,Enable,FC-AL},{XX,Disable,FC-AL},
{XX,Enable,P-to-P},{XX,Disable,P-to-P}],Num. of Ports=4
Detailed information
DescriptionItem
The name of the port where the topology of Fibre Channel is set.Port
Indicates whether the Fabric switch is enabled or disabled.Fabric
Enable: Enabled, Disable: Disabled
The connecting mode of the Fabric switch selected.Connection
FC-AL: FC-AL is selected, P-to-P: P-to-P is selected
The number of ports where the topology of Fibre Channel is set.Num. of Ports
[Install] Set Host Mode
Example
07xx,YYYY/MM/DD,HH:MM:SS.xxx, 00:00,SVP,uid=user-name,1,,
[Install],Set Host Mode,,Normal end,
from=xxxx:xxxx:xxxx:xxxx:xxxx:xxxx:xxxx:xxxx,,Seq.=xxxxxxxxxx
+{Port,HostGrpID,Mode,Option[0:31],Option[32:63],Option[64:95]}
=[{XX,0xXXX,0x00,0xXXXXXXXX,0xXXXXXXXX,0xXXXXXXXX},
{XX,0xXXX,0x4F,0xXXXXXXXX,0xXXXXXXXX,0xXXXXXXXX}],
Num. of Host Groups=2
Detailed information
DescriptionItem
The name of the port to which the host group belongs.Port
The host group number.HostGrpID
The host mode set. Please see the HP XP P9000 Provisioning for Open Systems User Guide for
the meaning of the host mode number.
Mode
The specified host mode option. 96 host mode options from 0 to 95 are output in groups of 32
options. Please see Table 13 (page 142) to Table 15 (page 143) for the relation of output values
and host mode option.
Option[0:31]
Option[32:63]
Option[64:95]
Please see the HP XP P9000 Provisioning for Open Systems User Guide for the meaning of the
host mode number.
The number of host groups that the host mode setting is changed.Num. of Host Groups
[Install] Set IP Address
Example
07xx,YYYY/MM/DD,HH:MM:SS.xxx, 00:00,SVP,uid=user-name,1,,
[Install],Set IPAddress,SVP and DKC,Normal end,
from=xxxx:xxxx:xxxx:xxxx:xxxx:xxxx:xxxx:xxxx,,Seq.=xxxxxxxxxx
98 Audit log examples
