HP XP7 Audit Log User and Reference Guide (H6F56-96001)

DescriptionItem
The LPR nameLPR
The level of Cache TuningCache Tuning
The number of LPRsNum. of LPRs
Command ControlCommand Control
The local mode numberMode
The setting status.Set
ON: Set, Off: Release
The number of local modes.Num. of Modes
Setting executed from the debug window (Set: fix).Debug Mode
Note: Only the changed items will be output.
[Install] System Tuning
Example
08xx,YYYY/MM/DD,HH:MM:SS.xxx, 00:00,SVP,uid=user-name,1,,
[Install],System Tuning,,Normal end,
from=xxxx:xxxx:xxxx:xxxx:xxxx:xxxx:xxxx:xxxx,,Seq.=xxxxxxxxxx
+Serial No.=64040
+IP Address Mode=Based on Serial Number
+IP Address=126.132.246.15
+Subnet Mask=255.0.0.0
+{Port,CU Number,Emulation}=[{1E,-,I-2107},
{3E,0x00:0x10-0x00:0x1F,I-2107},{5E,-,I-2107},{7E,-,I-2107}],
Num. of Ports=4
+{LDKC:CU,LDEV,SSID}=[{0x00:0x00,0x00-0xff,0x0005}],
Num. of SSIDs=1
+{TPF Enable,Number of MPLs}={ON,4096}
Detailed Information
DescriptionItem
The serial numberSerial No.
The IP address mode set.IP Address Mode
Based on Serial Number: Set the IP address from the serial number.
Specified: Set the specified IP address.
The IP address setIP Address
The subnet mask setSubnet Mask
The mounting location of the portPort
Indicates the range of the CU number that the port belongsCU Number
The emulation typeEmulation
The number of portsNum. of Ports
The LDKC number and the CU numberLDKC:CU
The LDEV numberLDEV
The storage system IDSSID
102 Audit log examples
