HP XP7 Audit Log User and Reference Guide (H6F56-96001)

Detailed Information
DescriptionItem
The parity group numberPG
E1-1: In case of an external volume
V1-1: In case of a virtual volume
X1-1: In case of a Thin Provisioning volume
The number of parity groupsNum. of PGs
The LDKC number, the CU number, and the LDEV numberLDEV
The number of LDEVs.Num. of LDEVs
[Maintenance] Replace
Example 1: replacing parts
08xx,YYYY/MM/DD,HH:MM:SS.xxx, 00:00,SVP,uid=user-name,1,,
[Maintenance], Replace,,Normal end,
from=xxxx:xxxx:xxxx:xxxx:xxxx:xxxx:xxxx:xxxx,,Seq.=xxxxxxxxxx
+Parts name=SSVPMN-0
Example 2: replacing SFP
08xx,YYYY/MM/DD,HH:MM:SS.xxx, 00:00,SVP,uid=user-name,1,,
[Maintenance], Replace,,Normal end,
from=xxxx:xxxx:xxxx:xxxx:xxxx:xxxx:xxxx:xxxx,,Seq.=xxxxxxxxxx
+SFP=[1A,3A,5A,7A],Num.of SFPs=4
Example 3: replacing Channel Adapter (CHA), Disk Adapter (DKA), cache memory, MPB,
and BKM
08xx,YYYY/MM/DD,HH:MM:SS.xxx, 00:00,SVP,uid=user-name,1,,
[Maintenance], Replace,,Normal end,
from=xxxx:xxxx:xxxx:xxxx:xxxx:xxxx:xxxx:xxxx,,Seq.=xxxxxxxxxx
+PCB=[CHA-1PC],Num. of PCBs=1
+Failed=[CHA-1PC],Num. of PCBs=1
Example 4: replacing PDEV (physical device)
08xx,YYYY/MM/DD,HH:MM:SS.xxx, 00:00,SVP,uid=user-name,1,,
[Maintenance], Replace,,Normal end,
from=xxxx:xxxx:xxxx:xxxx:xxxx:xxxx:xxxx:xxxx,,Seq.=xxxxxxxxxx
+PDEV=HDD000-00
+Copy=Restore Data
Example 5: replacing SSW
08xx,YYYY/MM/DD,HH:MM:SS.xxx, 00:00,SVP,uid=user-name,1,,
[Maintenance], Replace,,Normal end,
from=xxxx:xxxx:xxxx:xxxx:xxxx:xxxx:xxxx:xxxx,,Seq.=xxxxxxxxxx
+SSW=[SSW000-1],Num. of SSWs=1
Detailed Information
DescriptionItem
The name of the parts (DKCPS-xx, DKCFAN-xxx, DKCPANEL-x,SSVPMN-x, PCIADP, PCICON,
SVP-BASIC, SVP-OPTION, HUBBOX-xx, DKUPS-xxx, MODCON-x) specified to be replaced
Parts name
The port that Small Form-Factor Pluggables (SFPs) are inserted.SFP
The number of inserted Small Form-Factor PluggablesNum.of SFPs
114 Audit log examples
