HP XP7 Audit Log User and Reference Guide (H6F56-96001)

Example 3: Creating THP V-VOLs
08xx,YYYY/MM/DD,HH:MM:SS.xxx, 00:00,RMI AP,uid=user-name,1,
Task Name,[PROV],Create LDEVs,Thin Provisioning,Normal end,
from=xxxx:xxxx:xxxx:xxxx:xxxx:xxxx:xxxx:xxxx,,Seq.=xxxxxxxxxx
+{Pool ID,LDKC:CU:LDEV,LDEVCapa(blocks),Emulation,CLPR,SSID,
MP Blade ID,Attribute,Result}=[{1,0x00:0x00:0x00,96000,OPEN-V,
0,0x0004,Auto,-,Normal end},{1,0x00:0x01:0x00,96000,OPEN-V,
0,0x0005,Auto,-,Normal end}],Num.of LDEVs=2
Basic Information for Example 2 and 3
DescriptionItem
Operating for the Fast Snap volumes.Snapshot
Operating for the Thin Provisioning virtual volumes.Thin Provisioning
Detailed Information for Example 2 and 3
DescriptionItem
The pool ID of a related pool volumePool ID
For a Snapshot volume, a hyphen (-) is output, because you specify no setting about a related
volume when you create V-Vols for Snapshot.
The logical DKC, CU, and LDEV numbers of the created V-VolsLDKC:CU:LDEV
These numbers are separated by colons and arranged in this order.
The capacity of the created V-Vols in blocksLDEVCapa (blocks)
The emulation type of the created V-VolEmulation
The CLPR number of the created V-VolCLPR
The SSIDSSID
MP Blade ID specified for the V-Vol.MP Blade ID
When an MP Blade ID is specified automatically, "Auto" is output.
Indicates the attribute of the created V-VOLs.Attribute
TSE: TSE attribute, -: No attribute
This item is output for Thin Provisioning volumes only.
The result of the operationResult
Normal end: Normal end, Error(xxxx-yyyyy): Abnormal end
xxxx: Part code, yyyyy: Error code
The number of created V-VolsNum. of LDEVs
[PROV] Create Resource Grps
Example
08xx,YYYY/MM/DD,HH:MM:SS.xxx, 00:00,RMI AP,uid=user-name,1,
Task Name,[PROV],Create Resource Grps,,Normal end,
from=xxxx:xxxx:xxxx:xxxx:xxxx:xxxx:xxxx:xxxx,,Seq.=xxxxxxxxxx
+{VDKC-Box ID,Resource Group ID,Resource Group Name,Result}
=[{0,1,RSG1,Normal end},{0,2,RSG2,Normal end}],
Num. of Resource Groups=2
130 Audit log examples
