Table 17 Host mode option 96 to 127 and output contents of Option[96:127] (continued)
Value of Option[96:127]Host mode optionValue of Option[96:127]Host mode option
0x000000101230x00100000107
0x000000081240x00080000108
0x000000041250x00040000109
0x000000021260x00020000110
0x000000011270x00010000111
When more than one option is set, a logical sum of their values is output. For example, if
0x200C0000 is output to Option[0:31], it means the host mode options [2], [12], and [13] are
set.
[PROV] Edit Host Grps(Name)
Example
08xx,YYYY/MM/DD,HH:MM:SS.xxx, 00:00,RMI AP,uid=user-name,1,
Task Name,[PROV],Edit Host Grps(Name),,Normal end,
from=xxxx:xxxx:xxxx:xxxx:xxxx:xxxx:xxxx:xxxx,,Seq.=xxxxxxxxxx
+{Port,HostGrpID,HostGrpName}
=[{XX,0xXXX,XXXXXXXXXXXXXXXX},{XX,0xXXX,XXXXXXXXXXXXXXXX}],
Num. of Host Groups=2
Detailed Information
DescriptionItem
The name of the port to which the host group belongsPort
The host group number where the host group names have been changedHostGrpID
The name of the host group. If the name is changed, the name after change is indicatedHostGrpName
The number of host groups where the settings have been changedNum. of Host Groups
[PROV] Edit LDEVs(tier)
Example
08xx,YYYY/MM/DD,HH:MM:SS.xxx, 00:00,RMI AP,uid=user-name,1,
Task Name,[PROV],Edit LDEVs(tier),,Normal end,
from=xxxx:xxxx:xxxx:xxxx:xxxx:xxxx:xxxx:xxxx,,Seq.=xxxxxxxxxx
+{Pool ID,LDKC:CU:LDEV,Tier Relocation}
=[{1,0x00:0x01:0x0F,Disable}],Num. of LDEVs = 1
Detailed Information
DescriptionItem
The pool number of the edited LDEVPool ID
The LDKC number, CU number and the LDEV number of the edited volumeLDKC:CU:LDEV
Indicates whether the tier relocation is enabled or disabled.Tier Relocation
Enable: Enabled, Disable: Disabled
The number of edited LDEVsNum. of LDEVs
