HP XP7 Audit Log User and Reference Guide (H6F56-96001)

from=xxxx:xxxx:xxxx:xxxx:xxxx:xxxx:xxxx:xxxx,,Seq.=xxxxxxxxxx
+{VDKC-Box ID,Resource Group ID,Resource Group Name,Result}
=[{0,1,RSG1,Normal end}],Num. of Resource Groups=1
Detailed Information
DescriptionItem
The number of the VDKC-Box to which the configured resource group belongsVDKC-Box ID
The number of the configured resource groupResource Group ID
The contents of the setting for the changed resource group nameResource Group Name
The result of operationResult
Normal end: Normal end,
Error(xxxx-yyyyy): Abnormal end
where xxxx: Part code, yyyyy: Error code
The number of resource groups that operated the settingNum. of Resource
Groups
[PROV] Edit SCP Time
Example
08xx,YYYY/MM/DD,HH:MM:SS.xxx, 00:00,RMI AP,uid=user-name,1,
Task Name,[PROV],Edit SCP Time,,Normal end,
from=xxxx:xxxx:xxxx:xxxx:xxxx:xxxx:xxxx:xxxx,,Seq.=xxxxxxxxxx
+{CU,SCP Time(sec.)}=[{0x00,600},{0x01,600},(snip),{0xFE,600}],
Num. of CUs=255
Detailed Information
DescriptionItem
The CU numberCU
The SCP (State Change Pending) time in secondsSCP Time(sec.)
The number of CUs where the SCP time is setNum. of CUs
[PROV] Edit Tiering Policy
Example
08xx,YYYY/MM/DD,HH:MM:SS.xxx, 00:00,RMI AP,uid=user-name,1,
Task Name,[PROV],Edit Tiering Policy,,Normal end,
from=xxxx:xxxx:xxxx:xxxx:xxxx:xxxx:xxxx:xxxx,,Seq.=xxxxxxxxxx
+{Tiering Policy ID,Tier1 Max(%),Tier1 Min(%),Tier3 Max(%),
Tier3 Min(%),Result}
=[{6,90,10,90,10,Normal end}],Num. of Policies=1
Detailed Information
DescriptionItem
The tiering policy IDTiering Policy ID
The upper limit threshold value for the Tier1Tier1 Max(%)
The threshold value is displayed in the range 0 to 100. The unit is percent (%).
This is output when the upper limit threshold value for the Tier1 is set.
Provisioning Descriptions 147
