HP XP7 Audit Log User and Reference Guide (H6F56-96001)

DescriptionItem
The result of the operationResult
Normal end: Normal end,
Error(xxxx-yyyyy): Abnormal end
where xxxx: Part code, yyyyy: Error code
The number of created pairsNum. of Pairs
Example 4: when the copy type is Cnt Ac-J Z
08xx,YYYY/MM/DD,HH:MM:SS.xxx, 00:00,RMI AP,uid=user-name,1,,
[Remote Replication],Create Pairs,,Normal end,
from=xxxx:xxxx:xxxx:xxxx:xxxx:xxxx:xxxx:xxxx,,Seq.=xxxxxxxxxx
+Copy Type=Cnt Ac-J Z
+{P-VOL(LDKC:CU:LDEV),S-VOL(LDKC:CU:LDEV),MirrorID,S/N,
CTRLID,Priority,Initial Copy,M-JNL,R-JNL,Path Gr. ID,
Error Level,CFW,Result}
=[{0x00:0x00:0x00,0x00:0x20:0x00,0x00,65432,6,32,Entire,
0x002,0x000,Default,Mirror,Copy to S-VOL,Normal end},
-{0x00:0x00:0x01,0x00:0x20:0x01,0x00,65432,6,32,Entire,
0x002,0x000,Default,Mirror,Copy to S-VOL,Normal end}],
Num. of Pairs=2
Detailed Information 4
DescriptionItem
The program product name for this operationCopy Type
Cnt Ac-J Z: Continuous Access Journal Z
The LDKC, CU, and LDEV numbers of the primary data volumeP-VOL(LDKC:CU:LDEV)
The LDKC, CU, and LDEV numbers of the secondary data volumeS-VOL(LDKC:CU:LDEV)
The mirror IDMirrorID
The serial number of the RCUS/N
The controller ID of the RCUCTRLID
7: XP7, 6: P9500, 5: XP24000/XP20000 Disk Array, 19: HUS VM
The priority of the copy operationPriority
Indicates whether initial copy or paircreate operation for Delta resync is performed or not.Initial Copy
Entire: Perform initial copy, None: Do not perform initial copy,
Delta: Perform paircreate operation for Delta resync
The master journal numberM-JNL
The restore journal numberR-JNL
The path group ID specified for the storage systemPath Gr. ID
When the path group ID is default setting, "Default" is output.
The error levelError Level
Mirror: Mirror level, LU: LU level, Volume: Volume level
Indicates whether the setting to copy the CFW (Cache Fast Write) data to the secondary
volume is enabled or not.
CFW
Only P-VOL: Copy to primary volume only is enabled
Copy to S-VOL: Copy to primary and secondary volume is enabled
Remote Replication Descriptions 175
