HP XP7 Audit Log User and Reference Guide (H6F56-96001)

DescriptionItem
The controller ID of the RCUCTRLID
7: XP7, 6: P9500, 5: XP24000/XP20000 Disk Array, 19: HUS VM
The volume type of the deleted volumeType
P-VOL: Primary volume, S-VOL: Secondary volume
The delete rangeRange
Mirror: Mirror range, LU: LU range, Volume: Volume range
The delete modeDelete Mode
Normal: Normal mode, Force: Force mode
The result of the operationResult
Normal end: Normal end,
Error(xxxx-yyyyy): Abnormal end
where xxxx: Part code, yyyyy: Error code
The number of deleted pairsNum. of Pairs
Example 4: when the copy type is Cnt Ac-J Z
08xx,YYYY/MM/DD,HH:MM:SS.xxx, 00:00,RMI AP,uid=user-name,1,,
[Remote Replication],Delete Pairs,,Normal end,
from=xxxx:xxxx:xxxx:xxxx:xxxx:xxxx:xxxx:xxxx,,Seq.=xxxxxxxxxx
+Copy Type=Cnt Ac-J Z
+{P-VOL(LDKC:CU:LDEV),S-VOL(LDKC:CU:LDEV),MirrorID,S/N,
CTRLID,Type,Range,Delete Mode,Result}
=[{0x00:0x00:0x00,0x00:0x20:0x00,0x00,65432,6,P-VOL,Volume,
Normal,Normal end},
{0x00:0x00:0x02,0x00:0x20:0x02,0x00,65432,6,P-VOL,Volume,
Normal,Normal end}],Num. of Pairs=2
Detailed Information 4
DescriptionItem
The program product name for this operationCopy Type
Cnt Ac-J Z: Continuous Access Journal Z
The LDKC, CU, and LDEV numbers of the primary data volumeP-VOL(LDKC:CU:LDEV)
The LDKC, CU, and LDEV numbers of the secondary data volumeS-VOL(LDKC:CU:LDEV)
The mirror IDMirrorID
The serial number of the RCUS/N
The controller ID of the RCUCTRLID
7: XP7, 6: P9500, 5: XP24000/XP20000 Disk Array, 19: HUS VM
The volume type of the deleted volumeType
P-VOL: Primary volume, S-VOL: Secondary volume
The delete rangeRange
Mirror: Mirror range, LU: LU range, Volume: Volume range
The delete modeDelete Mode
Normal: Normal mode, Force: Force mode
178 Audit log examples
