Detailed Information
DescriptionItem
The serial number of the RCU on which a path is deletedS/N
The LDKC number of the connected LDKCMCU LDKC
The LDKC number of the paired LDKCRCU LDKC
The path group ID of the deleted path. When the path group ID is default setting, "Default"
is output.
Path Gr.ID
The controller ID of the RCU on which a path is deletedController ID
7: XP7, 6: P9500, 5: XP24000/XP20000 Disk Array, 19: HUS VM
The result of the operationResult
Normal end: Normal end,
Error(xxxx-yyyyy): Abnormal end
where xxxx: Part code, yyyyy: Error code
The CU number of the connected CUMCU
The CU number of the paired CURCU
The SSIDSSID
The port number of MCUMCU Port
The port number of RCURCU Port
The number of deleted port pairsNum. of Port Pairs
The number of RCUs setNum. of RCUs
[Remote Replication] Delete RCU
Example 1: when using CU Free
08xx,YYYY/MM/DD,HH:MM:SS.xxx, 00:00,RMI AP,uid=user-name,1,,
[Remote Replication],Delete RCU,,Normal end,
from=xxxx:xxxx:xxxx:xxxx:xxxx:xxxx:xxxx:xxxx,,Seq.=xxxxxxxxxx
+{S/N,MCU LDKC,RCU LDKC,Path Gr.ID,Controller ID,Result}
={99999,0x00,0x00,Default,6,Nomal end}
(Snip)
+{S/N,MCU LDKC,RCU LDKC,Path Gr.ID,Controller ID,Result}
={99998,0x00,0x00,Default,6,Nomal end}
+Num. of RCUs=xx
Example 2: when not using CU Free
08xx,YYYY/MM/DD,HH:MM:SS.xxx, 00:00,RMI AP,uid=user-name,1,,
[Remote Replication],Delete RCU,,Normal end,
from=xxxx:xxxx:xxxx:xxxx:xxxx:xxxx:xxxx:xxxx,,Seq.=xxxxxxxxxx
+{S/N,MCU LDKC,MCU,RCU LDKC,SSID,Result}
={99999,0x00,0x3F,0x00,0x0004,Nomal end}
(Snip)
+{S/N,MCU LDKC,MCU,RCU LDKC,SSID,Result}
={99998,0x00,0x3F,0x00,0x0004,Nomal end}
+Num. of RCUs=xx
Example 3: when using CU Free and not using CU Free coexist
08xx,YYYY/MM/DD,HH:MM:SS.xxx, 00:00,RMI AP,uid=user-name,1,,
[Remote Replication],Delete RCU,,Normal end,
from=xxxx:xxxx:xxxx:xxxx:xxxx:xxxx:xxxx:xxxx,,Seq.=xxxxxxxxxx
