hyphen (-) is output for a setting value, or a setting value is not output, or the item is not output.
See the log examples in the followings below for details.
• “Audit log examples” (page 44)
• “Audit log examples of commands sent from hosts, computers using RAID Manager, or hosts
using Business Continuity Manager ” (page 230)
The following shows the symbols used in the detailed information.
Table 3 Symbols Used in Detailed Parameter
DefinitionSymbol
'+' or '-' displays at the beginning of a line.+ and -
'+' means the beginning of the index. The number of occurrences of '+' represents the number of indents.
'-' means that the line continues from the previous line.
Connects an index and a setting value.=
When there is more than one setting value for an index, the setting values are enclosed by [ ], and
separated by a comma (,).
[ ]
Example: CU:LDEV=[0x00:0x00,0x00:0x01,0x00:0x02]
Details are enclosed by {}.{ }
Example: {Port,Fabric,Connection}=[{1E,ON,FC-AL},{3E,OFF,P-to-P}]
Supplementary and additional information for setting values are enclosed by ( ).( )
Example: {VOL(CU:LDEV),Result}={0x00:0x01,Error(xxxx-yyyy)}
Log output formats for different versions
Table 4 Format changes for each version number
ChangesVersion number
The log output format for DKCMAIN program version 80-01-2x-xx/xx (xx is a two-digit number.)
or later.
0802
Syslog file format
Syslog file format (RFC3164-compliant)
The following figure shows a sample syslog file.
