HP XP7 Audit Log User and Reference Guide (H6F56-96001)

=[{4C-0x00-0,4A-0x00-0,0x00,67676,6,32,0x000,LU,0x001,0x001,
Mirror,Normal,Normal end},
{4C-0x00-1,4A-0x00-1,0x00,67676,6,32,0x000,LU,0x001,0x001,
Mirror,Normal,Normal end}],
Num. of Pairs=2
Detailed Information 3
DescriptionItem
The program product name for this operationCopy Type
Cnt Ac-J: Continuous Access Journal
The port number, host group number, and LUN of the primary data volumeP-VOL(Port-G-ID-LUN)
The port number, host group number, and LUN of the secondary data volumeS-VOL(Port-G-ID-LUN)
The mirror IDMirrorID
The serial number of the RCUS/N
The controller ID of the RCUCTRLID
7: XP7, 6: P9500, 5: XP24000/XP20000 Disk Array, 19: HUS VM
The priority of the copy operationPriority
The consistency group IDCTG
The resync rangeRange
Mirror: Mirror range, LU: LU range, Volume: Volume range
The master journal numberM-JNL
The restore journal numberR-JNL
The error levelError Level
Mirror: Mirror level, LU: LU level, Volume: Volume level
Indicates the Resync ModeResync Mode
Normal: normal resync, Delta: delta resync, Return to standby: return to standby status
The result of the operationResult
Normal end: Normal end,
Error(xxxx-yyyyy): Abnormal end
where xxxx: Part code, yyyyy: Error code
The number of resynchronized pairsNum. of Pairs
Example 4: when the copy type is Cnt Ac-J Z
08xx,YYYY/MM/DD,HH:MM:SS.xxx, 00:00,RMI AP,uid=user-name,1,,
[Remote Replication],Resync Pairs,,Normal end,
from=xxxx:xxxx:xxxx:xxxx:xxxx:xxxx:xxxx:xxxx,,Seq.=xxxxxxxxxx
+Copy Type=Cnt Ac-J Z
+{P-VOL(LDKC:CU:LDEV),S-VOL(LDKC:CU:LDEV),MirrorID,S/N,CTRLID,
Priority,Range,M-JNL,R-JNL,Error Level,Resync Mode,Result}
=[{0x00:0x00:0x00,0x00:0x20:0x00,0x00,65432,6,7,Volume,0x002,
0x000,Volume,Normal,Normal end},
-{0x00:0x00:0x01,0x00:0x20:0x01,0x00,65432,6,7,Volume,0x003,
0x001,Volume,Normal,Normal end}],Num. of Pairs=2
192 Audit log examples
