HP XP7 Audit Log User and Reference Guide (H6F56-96001)

Detailed Information 4
DescriptionItem
The program product name for this operationCopy Type
Cnt Ac-J Z: Continuous Access Journal Z
The LDKC, CU, and LDEV numbers of the primary data volumeP-VOL(LDKC:CU:LDEV)
The LDKC, CU, and LDEV numbers of the secondary data volumeS-VOL(LDKC:CU:LDEV)
The mirror IDMirrorID
The serial number of the RCUS/N
The controller ID of the RCUCTRLID
7: XP7, 6: P9500, 5: XP24000/XP20000 Disk Array, 19: HUS VM
Indicates whether the split data volume is a primary or secondary data volumeType
P-VOL: Primary, S-VOL: Secondary
Indicates whether the writing to the secondary volume is enabledS-VOL Write
Disable: Disabled, Enable: Enabled
The split rangeRange
Mirror: Mirror range, LU: LU range, Volume: Volume range
The suspend modeSuspend Mode
Purge: Purge mode, Flush: Flush mode
The result of the operationResult
Normal end: Normal end,
Error(xxxx-yyyyy): Abnormal end
where xxxx: Part code, yyyyy: Error code
The number of split pairsNum. of Pairs
SNMP API Descriptions
[SNMP API] Edit SNMP Agent
Example
08xx,YYYY/MM/DD,HH:MM:SS.xxx, 00:00,RMI AP,uid=user-name,1,,
[SNMP API],Edit SNMP Agent,,Normal end,
from=xxxx:xxxx:xxxx:xxxx:xxxx:xxxx:xxxx:xxxx,,Seq.=xxxxxxxxxx
+Install=Disable
+Manager=[(158.214.133.1),(158.214.133.2),(158.214.133.3),
(1:0:0:0:0:0:0:1),(snip)
-(158.214.133.31),(158.214.133.32) ,(AAAA:0:0:0:0:0:0:FFFF)],
Num. of Managers=xx
+Community
=1234567891123456789212345678931234567894123456789512345678961234
56789712345678981234567899123456789012345678911234567892123456789
312345678941234567895
++Trap=[(158.214.133.1),(158.214.133.2),(158.214.133.3),
(1:0:0:0:0:0:0:1),(snip)
-(158.214.133.31),(158.214.133.32) ,(AAAA:0:0:0:0:0:0:FFFF)],
Num. of Traps=xx
(snip)
+Num. of Communities=xx
+System Group(Name,Contact,Location)
196 Audit log examples
