HP XP7 Audit Log User and Reference Guide (H6F56-96001)

={12345678911234567892123456789312345678941234567895123456789612
3456789712345678981234567899123456789012345678911234567892123456
78,
-123456789112345678921234567893123456789412345678951234567896123
4567897123456789812345678991234567890123456789112345678921234567
89312345678941234567895123456789612345,
-123456789112345678921234567893123456789412345678951234567896123
4567897123456789812345678991234567890123456789112345678921234567
89312345678941234567895123456789612345}
Detailed Information
DescriptionItem
The setting status of SNMP Agent:Install
Enable, Disable
The IP address of the registered SNMP manager. The IP address divided by periods (.) is
an Ipv4 address, and the IP address divided by colons (:) is an Ipv6 address.
Manager
The number of registered SNMP managersNum. of Managers
The registered community nameCommunity
The IP address where the trap of community is reported. The IP address divided by periods
(.) is an Ipv4 address, and the IP address divided by colons (:) is an Ipv6 address.
Trap
The number of traps reportedNum. of Traps
The number of registered communitiesNum. of Communities
The setting of system group information (Name, Contact, and Location).System Group
The nickname of the device set.Name
The setting name of the system administrator.Contact
The setting location of the device setLocation
Performance Control Descriptions
[Perf Ctl] Change PFCGrp
Example
08xx,YYYY/MM/DD,HH:MM:SS.xxx, 00:00,RMI AP,uid=user-name,1,,
[Perf Ctl],Change PFCGrp,,Normal end,
from=xxxx:xxxx:xxxx:xxxx:xxxx:xxxx:xxxx:xxxx,,Seq.=xxxxxxxxxx
+{PFC Group,Priority,UpperLimit,Mode}
=[{XXXXXXXXXXXXXXXX,Non-Prio,XXXXXXXX,IOPS}],Num. of PFC Groups=1
Detailed Information
DescriptionItem
A PFC group namePFC Group
An attribute specified to an HBA (host bus adapter) in the PFC group after the changePriority
Prio: a prioritized WWN
Non-Prio: a non-prioritized WWN
An upper limit when you specify Non-PrioUpper Limit
When you specify Prio, this information is not output.
Performance Control Descriptions 197
