HP XP7 Audit Log User and Reference Guide (H6F56-96001)

DescriptionItem
The type of rate when you specify an upper limit.Mode
IOPS: the I/O rate
KB/s: the transfer rate
When you specify Prio, this information is not output.
The number of PFC groups whose settings are changedNum. of PFC Groups
NOTE:
• When the attribute of the host bus adapter in the PFC group changes from a prioritized WWN
to a non-prioritized WWN, "Non-Prio" is output to Priority and "0" is output to Upper limit
respectively.
• If multiple changes in settings such as Priority and Upper limit are made in succession and
then Apply is clicked at the end of the operation, these set values are output one by one in
the order they were configured.
[Perf Ctl] Clear PFC Info
Example
08xx,YYYY/MM/DD,HH:MM:SS.xxx, 00:00,RMI AP,uid=user-name,1,,
[Perf Ctl],Clear PFC Info,,Normal end,
from=xxxx:xxxx:xxxx:xxxx:xxxx:xxxx:xxxx:xxxx,,Seq.=xxxxxxxxxx
[Perf Ctl] Default Set
Example
08xx,YYYY/MM/DD,HH:MM:SS.xxx, 00:00,RMI AP,uid=user-name,1,,
[Perf Ctl],Default Set,Kind=WWN,Normal end,
from=xxxx:xxxx:xxxx:xxxx:xxxx:xxxx:xxxx:xxxx,,Seq.=xxxxxxxxxx
Basic Information
DescriptionParameter
Indicates that settings in the Port tab are initialized.Kind=Port
Indicates that settings in the WWN tab are initialized.Kind=WWN
[Perf Ctl] Set All Prio Port
Example
08xx,YYYY/MM/DD,HH:MM:SS.xxx, 00:00,RMI AP,uid=user-name,1,,
[Perf Ctl],Set All Prio Port,,Normal end,
from=xxxx:xxxx:xxxx:xxxx:xxxx:xxxx:xxxx:xxxx,,Seq.=xxxxxxxxxx
+{AllPriority,Threshold,Mode}={Enable,XXXXXXXX,IOPS}
Detailed Information
DescriptionItem
Settings in the All Thresholds field in the Port tabAllPriority
Enable: All Thresholds is configured.
198 Audit log examples
