HP XP7 Audit Log User and Reference Guide (H6F56-96001)

DescriptionItem
When the WWN is a non-prioritized WWN, this information indicates the upper limit.Upper Limit
When the WWN is a prioritized WWN, this information is not output.
The type of rate for the upper limitMode
IOPS: the I/O rate
KB/s: the transfer rate
This information is not output when the WWN is a prioritized WWN.
The number of WWNs of HBAs whose settings are changedNum. of WWNs
NOTE:
• When the attribute of the host bus adapter changes from a prioritized WWN to a
non-prioritized WWN, "Non-Prio" is output to Priority and "0" is output to Upper limit
respectively.
• If multiple changes in settings such as Priority and Upper limit are made in succession and
then Apply is clicked at the end of the operation, these set values are output one by one in
the order they were configured.
[Perf Ctl] PFCGrp Del/Chg
Example
08xx,YYYY/MM/DD,HH:MM:SS.xxx, 00:00,RMI AP,uid=user-name,1,,
[Perf Ctl],PFCGrp Del/Chg,,Normal end,
from=xxxx:xxxx:xxxx:xxxx:xxxx:xxxx:xxxx:xxxx,,Seq.=xxxxxxxxxx
+{Mode,PFC Group,Change Name}
=[{Update,XXXXXXXXXXXXXXXX,XXXXXXXXXXXXXXXX}],
Num. of PFC Groups=1
Detailed Information
DescriptionItem
An executed operationMode
Delete: Deleted a PFC group.
Update: Changed a PFC name.
A PFC group name where the operation is executedPFC Group
A PFC group name after the changeChange Name
This information is output only when a PFC group name is changed.
The number of PFC groups that are deleted or whose names are changedNum. of PFC Groups
[Perf Ctl] Update Port WWN
Example
08xx,YYYY/MM/DD,HH:MM:SS.xxx, 00:00,RMI AP,uid=user-name,1,,
[Perf Ctl],Update Port WWN,,Normal end,
from=xxxx:xxxx:xxxx:xxxx:xxxx:xxxx:xxxx:xxxx,,Seq.=xxxxxxxxxx
+{Mode,WWN,PFC Name,Priority}
={Add WWN,0xXXXXXXXXXXXXXXXX,XXXXXXXXXXXXXXXX,Non-Prio},
++Port=[1A,3A],Num. of Ports=2,
-Num. of WWNs=1
Performance Control Descriptions 201
