HP XP7 Audit Log User and Reference Guide (H6F56-96001)

DescriptionItem
The serial number the external storage system that the mapped external volume existsSerial
The identification character 1 of the mapped external volumeVolumeID1
The identification character 2 of the mapped external volumeVolumeID2
The device name that the mapped external volume notifies to the hostDevice
The capacity of the mapped external volume indicated by blocksCapa(blocks)
The number of the external volume group and the reference number assigned to the external
volume of the mapped external volume. The number on the left of a dash (-) is the external
ExGroup
volume number and the number on the right of the dash (-) is the reference number of the
group.
The path group number of the mapped external volumePathGroup
The CLPR number of the mapped external volumeCLPR
The emulation type of the mapped external volumeEmulation
The cache mode of the mapped external volumeCache
Enable: Enabled, Disable: Disabled
The inflow control setting of the cache of the mapped external volume.Inflow
Enable: Enabled, Disable: Disabled
MP Blade ID specified for the external volumeMP Blade ID
When an MP Blade ID is specified automatically, "Auto" is output.
The load balance mode of the mapped external volumeLoadBalanceMode
Normal Round-robin, Extended Round-robin, or Disable will appear.
The ALUA permitted of the mapped external volumeALUA Permitted
Enable: Enabled, Disable: Disabled
The result of the operationResult
Normal end: Normal end,
Error(xxxx-yyyyy): Abnormal end
where xxxx: Part code, yyyyy: Error code
The port name of the external port of the local storage systemPort
The WWN of the Target port of the external storage systemWWN
The LUN of the external volumeLUN
The number of mapping path (Port-WWN-LUN) configuredNum. of Paths
The result of attempting to create an external path.PathResult
If the path is created normally, the audit log includes the following:
PathResult: Normal end
If the path is not created, the audit log includes this:
PathResult: Error(xxxx-yyyyy): Abnormal end
where xxxx is the Part code and yyyyy is the Error code
The LDKC number, CU, and LDEV number of the LDEVs in the mapped external volume. The
number on the left of the colon is an LDKC number, the number between the colons is a CU
number, and the number on the right of the colon is an LDEV number
LDKC:CU:LDEV
The capacity of LDEVs in the mapped external volumes indicated by blocksLDEVCapa(blocks)
The SSIDSSID
External Storage Descriptions 205
