HP XP7 Audit Log User and Reference Guide (H6F56-96001)

DescriptionItem
MP Blade ID specified for the LDEV.LDEV MP Blade ID
When an MP Blade ID is specified automatically, "Auto" is output.
The result of attempting to create an external path.LDEVResult
If the LDEV is created normally, the audit log includes the following:
LDEVResult: Normal endIf the LDEV is not created, the audit log includes this:LDEVResult:
Error(xxxx-yyyyy): Abnormal end where xxxx is the Part code and yyyyy is the Error code
The number of LDEVs in the mapped external volumesNum. of LDEVs
The number of mapped external volumesNum. of Volumes
[Ext Stor] Assign MP Blade
Example
08xx,YYYY/MM/DD,HH:MM:SS.xxx, 00:00,RMI AP,uid=user-name,1,
Task Name,[Ext Stor],Assign MP Blade,,Normal end,
from=xxxx:xxxx:xxxx:xxxx:xxxx:xxxx:xxxx:xxxx,,Seq.=xxxxxxxxxx
+{Group,MP Blade ID,Result}=[{E1-1,0x0,Normal end},
{E1-2,0x1,Normal end},{E1-3,0x2,Normal end}],Num. of Groups=3
Detailed Information
DescriptionItem
The external volume number for the configured external volumesGroup
The MP Blade ID assigned to the external volumeMP Blade ID
The result of operationResult
Normal end: Normal end,
Error(xxxx-yyyyy): Abnormal end
where xxxx: Part code, yyyyy: Error code
The number of groups of configured external volumesNum. of Groups
[Ext Stor] Delete ES VOLs
Example
08xx,YYYY/MM/DD,HH:MM:SS.xxx, 00:00,RMI AP,uid=user-name,1,
Task Name,[Ext Stor],Delete ES VOLs,,Normal end,
from=xxxx:xxxx:xxxx:xxxx:xxxx:xxxx:xxxx:xxxx,,Seq.=xxxxxxxxxx
+{ExGroup,Mode,Result}=[{E1-1,Force,Normal end},{E1-2,Force,
Normal end},{E1-3,Normal,Normal end}],Num. of Volumes=3
Detailed Information
DescriptionItem
The number of the external volume group and the reference number assigned to the external
volume of the external volume that the mapping has been released. The number on the left
ExGroup
of a dash (-) is the external volume number and the number on the right of the dash (-) is the
reference number of the group.
The mode of execution when mapping was releasedMode
Normal: normal execution. Force: forcible execution
The result of operationResult
