Detailed Information
DescriptionItem
The logical volume ID of the migration source. The number on the left of the colon is an LDKC
number, the number between the colons is a CU number, and the number on the right of
the colon is an LDEV number.
SourceVolume
The logical volume ID of the migration target. The number on the left of the colon is an LDKC
number, the number between the colons is a CU number, and the number on the right of
the colon is an LDEV number.
TargetVolume
The application by which a migration plans to be deleted is set.OwnerID
0x00: Remote Web Console
0x01: RAID Manager
0xFF: Tiered Storage Manager
A hyphen (-) is output, no matter which application is used for a migration plan to be set, if
the plan is deleted from the Auto LUN window.
The result of operationResult
Normal end: Normal end,
Error(xxxx-yyyyy): Abnormal end,
Not Execute: Not executed
where xxxx: Part code, yyyyy: Error code
The number of migration plans deleted.Num. of Plans
[Auto LUN] Migrate Volumes
This logged information indicates that the migration was only requested but not completed.
Example
08xx,YYYY/MM/DD,HH:MM:SS.xxx, 00:00,RMI AP,uid=user-name,1,,
[Auto LUN],Migrate Volumes,,Normal end,
from=xxxx:xxxx:xxxx:xxxx:xxxx:xxxx:xxxx:xxxx,,Seq.=xxxxxxxxxx
+{SourceVolume,TargetVolume,OwnerID,Migration Type,Result}
=[{0x00:0x00:0x00,0x00:0x00:0x01,0x00,Online Data Migration,
Normal end},
{0x00:0x00:0x02,0x00:0x00:0x03,0xFF,Normal,Error(xxxx-yyyyy)},
{0x00:0x00:0x04,0x00:0x00:0x05,0x00,Normal,Normal end},
{0x00:0x00:0x06,0x00:0x00:0x07,0xFF,Online Data Migration,
Error(xxxx-yyyyy)}],Num. of VOLs=4
Detailed Information
DescriptionItem
The logical volume ID of the migration source. The number on the left of the colon is an LDKC
number, the number between the colons is a CU number, and the number on the right of
the colon is an LDEV number.
SourceVolume
The logical volume ID of the migration target. The number on the left of the colon is an LDKC
number, the number between the colons is a CU number, and the number on the right of
the colon is an LDEV number. This value is output only when the migration plan is set.
TargetVolume
The application by which a migration plans is set.OwnerID
0x00: Remote Web Console
0x01: RAID Manager
0xFF: Tiered Storage Manager
The migration type of the migration plan.Migration Type
