HP XP7 Audit Log User and Reference Guide (H6F56-96001)

Add LUN
Example
08xx,YYYY/MM/DD,HH:MM:SS.xxx, 00:00,Out-of-band OPEN,uid=user-name,
196,,[Config Command],,,Accept,
from=xxxx:xxxx:xxxx:xxxx:xxxx:xxxx:xxxx:xxxx,,Seq.=xxxxxxxxxx
+Command=Add LUN
++Port=1A,Host Group ID=0xXX,LUN=A,
LDEV(LDKC:CU:LDEV)=0x00:0xAA:0xBB,
Virtual Storage Machine S/N=23456
+0000010200000000 0000000000000000
+0123456789ABCDEF 0123456789ABCDEF 0123456789ABCDEF,(snip)
Detailed Information
DescriptionItem
The command nameCommand
The name of a port to which an LU is addedPort
When a virtual storage machine is specified, the port name of the virtual storage
machine is output.
The ID of a host group to which an LU is addedHost Group ID
The LU number to be addedLUN
The LDKC number, the CU number, and the LDEV number of an LDEV to be set as an
LU.
LDEV(LDKC:CU:LDEV)
The serial number of the virtual storage machineVirtual Storage Machine S/N
No output when a virtual storage machine is not specified
Indicates the 16 byte parameter added in the storage system and the command
parameter in binary format
Command parameter
Add Path
Example
08xx,YYYY/MM/DD,HH:MM:SS.xxx, 00:00,Out-of-band,uid=user-name,
196,,[Config Command],,,Accept,
from=xxxx:xxxx:xxxx:xxxx:xxxx:xxxx:xxxx:xxxx,,Seq.=xxxxxxxxxx
+Command=Add Path
++Port=1B,WWN=XXXXXXXXXXXXXXXX,Path Group ID=A
+0000010200000000 0000000000000000
+0123456789ABCDEF 0123456789ABCDEF 0123456789ABCDEF,(snip)
Detailed Information
DescriptionParameter
The command nameCommand
The port name of the external storage systemPort
The WWN of the external storage systemWWN
The path group ID of the external volumePath Group ID
Indicates the 16 byte parameter added in the storage system and the command
parameter in binary format
Command parameter
Config Command (Open system) 235
