Detailed Information
DescriptionItem
The command nameCommand
The journal group numberJNLG
The LDKC number, the CU number, and the LDEV number of a journal volume to be
deleted
LDEV(LDKC:CU:LDEV)
The number of journal volumes to be deletedNum. of LDEVs
Indicates the 16 byte parameter added in the storage system and the command
parameter in binary format
Command parameter
Delete Ldev
Example
08xx,YYYY/MM/DD,HH:MM:SS.xxx, 00:00,Out-of-band,uid=user-name,
196,,[Config Command],,,Accept,
from=xxxx:xxxx:xxxx:xxxx:xxxx:xxxx:xxxx:xxxx,,Seq.=xxxxxxxxxx
+Command=Delete Ldev
++LDEV(LDKC:CU:LDEV)=0x00:0xAA:0xBB
+0000010200000000 0000000000000000
+0123456789ABCDEF 0123456789ABCDEF 0123456789ABCDEF,(snip)
Detailed Information
DescriptionItem
The command nameCommand
The LDKC number, the CU number, and the LDEV number of an LDEV to be deletedLDEV(LDKC:CU:LDEV)
Indicates the 16 byte parameter added in the storage system and the command
parameter in binary format
Command parameter
Delete LUN
Example
08xx,YYYY/MM/DD,HH:MM:SS.xxx, 00:00,Out-of-band,uid=user-name,
196,,[Config Command],,,Accept,
from=xxxx:xxxx:xxxx:xxxx:xxxx:xxxx:xxxx:xxxx,,Seq.=xxxxxxxxxx
+Command=Delete LUN
++Port=1A,Host Group ID=0xXX,LUN=A,
LDEV(LDKC:CU:LDEV)=0x00:0xAA:0xBB,
Virtual Storage Machine S/N=23456
+0000010200000000 0000000000000000
+0123456789ABCDEF 0123456789ABCDEF 0123456789ABCDEF,(snip)
Detailed Information
DescriptionItem
The command nameCommand
The name of a port from which an LU is deletedPort
When a virtual storage machine is specified, the port name of the virtual storage
machine is output.
The ID of a host group from which an LU is deletedHost Group ID
