Modify Ldev(CLPR)
Example
08xx,YYYY/MM/DD,HH:MM:SS.xxx, 00:00,Out-of-band,uid=user-name,
196,,[Config Command],,,Accept,
from=xxxx:xxxx:xxxx:xxxx:xxxx:xxxx:xxxx:xxxx,,Seq.=xxxxxxxxxx
+Command=Modify Ldev(CLPR)
++LDEV(LDKC:CU:LDEV)=0x00:0xAA:0xBB,CLPR=AA
+0000010200000000 0000000000000000
+0123456789ABCDEF 0123456789ABCDEF 0123456789ABCDEF,(snip)
Detailed Information
DescriptionItem
The command nameCommand
The LDKC number, the CU number, and the LDEV number of an LDEV in which the
CLPR is changed
LDEV(LDKC:CU:LDEV)
The number of the CLPR number to be changedCLPR
Indicates the 16 byte parameter added in the storage system and the command
parameter in binary format
Command parameter
Modify Ldev(Command Device)
Example
08xx,YYYY/MM/DD,HH:MM:SS.xxx, 00:00,Out-of-band,uid=user-name,
196,,[Config Command],,,Accept,
from=xxxx:xxxx:xxxx:xxxx:xxxx:xxxx:xxxx:xxxx,,Seq.=xxxxxxxxxx
+Command=Modify Ldev(Command Device)
++LDEV(LDKC:CU:LDEV)=0x00:0xFE:0xFF,Command Device=Disable,
Security=Disable,UserAuth=Disable
+0000010200000000 0000000000000000
+0123456789ABCDEF 0123456789ABCDEF 0123456789ABCDEF,(snip)
Detailed Information
DescriptionItem
The command nameCommand
The LDKC number, the CU number, and the LDEV number of an LDEV to be setLDEV(LDKC:CU:LDEV)
Indicates whether the attribute of the command device is enabled or disabledCommand Device
Enable or Disable will appear
Indicates whether the command device security is enabled or disabledSecurity
Disable or Enable will appear
Indicates whether the user authentication is enabled or disabledUserAuth
Disable or Enable will appear
Indicates the 16 byte parameter added in the storage system and the command
parameter in binary format
Command parameter
