DescriptionItem
The serial number of the remote storage systemRCU S/N*
The SSID to which a volume for the remote storage system belongsRCU SSID*
No output if it is not specified at the command option
Indicates the direction of resynchronizing a pairResync Type
Normal: Normal direction (Primary volume to secondary volume)
Reverse: Reverse direction (Secondary volume to primary volume.)
This item is output only when the Copy Kind is Local.
The serial number of the virtual storage machineVirtual Storage Machine S/N
No output when a virtual storage machine is not specified
Indicates the 16 byte parameter added in the storage system and the command
parameter in binary format
Command parameter
*When a virtual storage machine is specified, the value of the virtual storage machine is output.
Pairsplit
Example
08xx,YYYY/MM/DD,HH:MM:SS.xxx, 00:00,Out-of-band,uid=user-name,
196,,[Config Command],,,Accept,
from=xxxx:xxxx:xxxx:xxxx:xxxx:xxxx:xxxx:xxxx,,Seq.=xxxxxxxxxx
+Command=Pairsplit
++Copy Kind=Remote
++P-VOL(Port-LUN-LDEV)=1A-2047-0x1A,
S-VOL(Port-LUN-LDEV)=1B-3-0x3B,
MCU S/N=12345,MCU SSID=0x6500,RCU S/N=22364,RCU SSID=0x3001,
Range=LU,Virtual Storage Machine S/N=23456
+0000010200000000 0000000000000000
+0123456789ABCDEF 0123456789ABCDEF 0123456789ABCDEF,(snip)
Detailed Information
DescriptionItem
The command nameCommand
Indicates whether the copy kind is Local copy or Remote copyCopy Kind
Local: Local copy, Remote: Remote copy
The port number, the LU number, and the LDEV number of the primary volumeP-VOL(Port-LUN-LDEV)*
The port number and the LU number show the expanded LU of RAID Manager
No output when the pair operation is performed by RAID Manager from the remote
storage system
The port number, the LU number, and the LDEV number of the secondary volumeS-VOL(Port-LUN-LDEV)*
The port number and the LU number show the expanded LU of RAID Manager
The serial number of the local storage systemMCU S/N*
No output when the pair operation is performed by RAID Manager from the remote
storage system
The SSID to which a volume for the local storage system belongsMCU SSID*
No output if it is not specified at the command option
The serial number of the remote storage systemRCU S/N*
