from=xxxx:xxxx:xxxx:xxxx:xxxx:xxxx:xxxx:xxxx,,Seq.=xxxxxxxxxx
+Command=Unmap Resource(LDEV)
++LDEV(LDKC:CU:LDEV)=0x00:0xAA:0xBB,
Map LDEV(LDKC:CU:LDEV)=0x00:0xCC:0xDD
+0000010200000000 0000000000000000
+0123456789ABCDEF 0123456789ABCDEF 0123456789ABCDEF,(snip)
Detailed Information
DescriptionItem
The command nameCommand
The LDKC number, the CU number, and the LDEV number of the actual volumeLDEV(LDKC:CU:LDEV)
The virtual LDKC number, the virtual CU number, and the virtual LDEV number, whose
assignments to the actual volume are released
Map LDEV(LDKC:CU:LDEV)
Indicates the 16 byte parameter added in the storage system and the command
parameter in binary format
Command parameter
Unmap Resource(Port)
Example
08xx,YYYY/MM/DD,HH:MM:SS.xxx, 00:00,Out-of-band,uid=user-name,
196,,[Config Command],,,Accept,
from=xxxx:xxxx:xxxx:xxxx:xxxx:xxxx:xxxx:xxxx,,Seq.=xxxxxxxxxx
+Command=Unmap Resource(Port)
++Port=1A,Map Port=1E
+0000010200000000 0000000000000000
+0123456789ABCDEF 0123456789ABCDEF 0123456789ABCDEF,(snip)
Detailed Information
DescriptionItem
The command nameCommand
The port name of the actual portPort
The name of the virtual port whose assignment to the actual port is releasedMap Port
Indicates the 16 byte parameter added in the storage system and the command
parameter in binary format
Command parameter
Config Command (Mainframe system)
The following shows examples and descriptions of the audit logs when a storage system receives
commands sent from hosts for mainframe system, computers using RAID Manager, or hosts using
Business Continuity Manager.
Business Continuity Manager
Add CTG
Example
08xx,YYYY/MM/DD,HH:MM:SS.xxx, 00:00,In-band MF,uid=user-name,
,,[Config Command],,,Accept,
from=xxxx:xxxx:xxxx:xxxx:xxxx:xxxx:xxxx:xxxx,,Seq.=xxxxxxxxxx
+Command=Add CTG
++Copy Type=Cnt Ac-S Z,CTG=0x11
