HP XP7 Audit Log User and Reference Guide (H6F56-96001)

DescriptionParameter
This item is output only when the copy type is Cnt Ac-J Z.
Indicates the 16 byte parameter added in the storage system and the command
parameter in binary format
Command parameter
Add RCU
Example
08xx,YYYY/MM/DD,HH:MM:SS.xxx, 00:00,In-band MF,uid=user-name,
,,[Config Command],,,Accept,
from=xxxx:xxxx:xxxx:xxxx:xxxx:xxxx:xxxx:xxxx,,Seq.=xxxxxxxxxx
+Command=Add RCU
++MCU S/N=12345,MCU SSID=0x3000,RCU S/N=22345,RCU SSID=0x3001,
Controller ID=7
++{MCU Port,RCU Port,RCU CU}
=[{1A,1B,0x00},{2A,2B,0x01},{3A,3B,0x02}],Num.of Paths=3
+0000010200000000 0000000000000000
+0123456789ABCDEF 0123456789ABCDEF 0123456789ABCDEF,(snip)
Detailed Information
DescriptionParameter
The command nameCommand
The serial number of the local storage systemMCU S/N
The SSID to which a volume for the local storage system belongsMCU SSID
No output if it is not specified at the command option
The serial number of the remote storage systemRCU S/N
The SSID to which a volume for the remote storage system belongsRCU SSID
No output if it is not specified at the command option
The controller ID of the remote storage systemController ID
7: XP7, 6: P9500, 5: XP24000/XP20000 Disk Array, 19: HUS VM
No output if it is not specified at the command option
The port name of the local storage systemMCU Port
The port name of the remote storage systemRCU Port
The CU number of the remote storage systemRCU CU
The number of paths to be createdNum. of Paths
Indicates the 16 byte parameter added in the storage system and the command
parameter in binary format
Command parameter
At-time Split
Example
08xx,YYYY/MM/DD,HH:MM:SS.xxx, 00:00,In-band MF,uid=user-name,
,,[Config Command],,,Accept,
from=xxxx:xxxx:xxxx:xxxx:xxxx:xxxx:xxxx:xxxx,,Seq.=xxxxxxxxxx
+Command=At-time Split
++Copy Type=BC Z,Kind=Set,CTG=0x11
+0000010200000000 0000000000000000
+0123456789ABCDEF 0123456789ABCDEF 0123456789ABCDEF,(snip)
Config Command (Mainframe system) 279
