HP XP7 Audit Log User and Reference Guide (H6F56-96001)

DescriptionParameter
Cnt Ac-J Z: Continuous Access Journal Z
The CU number and the LDEV number of the primary volumeP-VOL(CU:LDEV)
The CU number and the LDEV number of the secondary volumeS-VOL(CU:LDEV)
The serial number of the local storage systemMCU S/N
The SSID to which a volume for the local storage system belongsMCU SSID
The serial number of the remote storage systemRCU S/N
The SSID to which a volume for the remote storage system belongsRCU SSID
Indicates the 16 byte parameter added in the storage system and the command
parameter in binary format
Command parameter
Delete RCU
Example
08xx,YYYY/MM/DD,HH:MM:SS.xxx, 00:00,In-band MF,uid=user-name,
,,[Config Command],,,Accept,
from=xxxx:xxxx:xxxx:xxxx:xxxx:xxxx:xxxx:xxxx,,Seq.=xxxxxxxxxx
+Command=Delete RCU
++MCU S/N=12345,MCU SSID=0x3000,RCU S/N=22345,RCU SSID=0x3001,
Controller ID=7
+0000010200000000 0000000000000000
+0123456789ABCDEF 0123456789ABCDEF 0123456789ABCDEF,(snip)
Detailed Information
DescriptionParameter
The command nameCommand
The serial number of the local storage systemMCU S/N
The SSID to which a volume for the local storage system belongsMCU SSID
No output if it is not specified at the command option
The serial number of the remote storage systemRCU S/N
The SSID to which a volume for the remote storage system belongsRCU SSID
No output if it is not specified at the command option
The controller ID of the remote storage systemController ID
7: XP7, 6: P9500, 5: XP24000/XP20000 Disk Array, 19: HUS VM
No output if it is not specified at the command option
Indicates the 16 byte parameter added in the storage system and the command
parameter in binary format
Command parameter
EXCTG
Example
08xx,YYYY/MM/DD,HH:MM:SS.xxx, 00:00,In-band MF,uid=user-name,
,,[Config Command],,,Accept,
from=xxxx:xxxx:xxxx:xxxx:xxxx:xxxx:xxxx:xxxx,,Seq.=xxxxxxxxxx
+Command=EXCTG
++EXCTG=0x03,Command=Add,Mirror ID=0x03
++{Slv S/N,Slv Controller ID,JNLG,Slv Cmd DEV(CU:LDEV)}
282 Audit log examples of commands sent from hosts, computers using RAID Manager, or hosts using Business Continuity Manager
