HP XP7 Audit Log User and Reference Guide (H6F56-96001)

=[{12345,5,0x0FF,0xFE:0xFF},{12345,5,0x0FF,0xAB:0xFF},
{12345,5,0x0FF,0x03:0xFF}],Num. of JNLG=3
+0000010200000000 0000000000000000
+0123456789ABCDEF 0123456789ABCDEF 0123456789ABCDEF,(snip)
Detailed Information
DescriptionParameter
The command nameCommand
The extended consistency group IDEXCTG
Indicates whether to register or delete the extended consistency groupCommand
Add: Register, Delete: Delete
The mirror IDMirror ID
The serial number of the remote storage systemSlv S/N
The controller ID of the remote storage systemSlv Controller ID
7: XP7, 6: P9500, 5: XP24000/XP20000 Disk Array, 19: HUS VM
The journal group numberJNLG
The CU number and the LDEV number of the command device for the remote storage
system
Slv Cmd DEV(CU:LDEV)
No output if the storage system is used as a super DKC
The number of journal groupsNum. of JNLG
Indicates the 16 byte parameter added in the storage system and the command
parameter in binary format
Command parameter
Freeze
Example
08xx,YYYY/MM/DD,HH:MM:SS.xxx, 00:00,In-band MF,uid=user-name,
,,[Config Command],,,Accept,
from=xxxx:xxxx:xxxx:xxxx:xxxx:xxxx:xxxx:xxxx,,Seq.=xxxxxxxxxx
+Command=Freeze
++VOL(CU:LDEV)=0xAA:0xBB,CTG=0x11
+0000010200000000 0000000000000000
+0123456789ABCDEF 0123456789ABCDEF 0123456789ABCDEF,(snip)
Detailed Information
DescriptionParameter
The command nameCommand
The CU number and the LDEV number of the volume which is a target of FREEZEVOL(CU:LDEV)
The consistency group which is a target of FREEZECTG
Indicates the 16 byte parameter added in the storage system and the command
parameter in binary format
Command parameter
Remote DKC Control
Example
08xx,YYYY/MM/DD,HH:MM:SS.xxx, 00:00,In-band MF,uid=user-name,
,,[Config Command],,,Accept,
from=xxxx:xxxx:xxxx:xxxx:xxxx:xxxx:xxxx:xxxx,,Seq.=xxxxxxxxxx
Config Command (Mainframe system) 283
