HP XP7 Audit Log User and Reference Guide (H6F56-96001)

EST PAIR
Example
08xx,YYYY/MM/DD,HH:MM:SS.xxx, 00:00,In-band MF,uid=user-name,,,
[Config Command],,,Accept,
from=xxxx:xxxx:xxxx:xxxx:xxxx:xxxx:xxxx:xxxx,,Seq.=xxxxxxxxxx
+Command=EST PAIR
++P-VOL(LDEV)=0xAA,S-VOL(LDEV)=0xBB,MCU S/N=12345,
MCU SSID=0x1234,RCU S/N=23456,RCU SSID=0x2345
+0000010200000000 0000000000000000
+0123456789ABCDEF 0123456789ABCDEF 0123456789ABCDEF,(snip)
Detailed Information
DescriptionParameter
The command nameCommand
The LDEV number of the primary volumeP-VOL(LDEV)
The LDEV number of the secondary volumeS-VOL(LDEV)
The serial number of the local storage systemMCU S/N
The SSID to which a volume for the local storage system belongsMCU SSID
The serial number of the remote storage systemRCU S/N
The SSID to which a volume for the remote storage system belongsRCU SSID
Indicates the 16 byte parameter added in the storage system and the command
parameter in binary format
Command parameter
EST PATH
Example
08xx,YYYY/MM/DD,HH:MM:SS.xxx, 00:00,In-band MF,uid=user-name,,,
[Config Command],,,Accept,
from=xxxx:xxxx:xxxx:xxxx:xxxx:xxxx:xxxx:xxxx,,Seq.=xxxxxxxxxx
+Command=EST PATH
++MCU S/N=12345,MCU SSID=0x1234,RCU S/N=23456,RCU SSID=0x2345
++{MCU Port,RCU Port,RCU CU}
=[{1A,1B,0x00},{2A,2B,0x00},{3A,3B,0x00}],Num.of Paths=3
+0000010200000000 0000000000000000
+0123456789ABCDEF 0123456789ABCDEF 0123456789ABCDEF,(snip)
Detailed Information
DescriptionParameter
The command nameCommand
The serial number of the local storage systemMCU S/N
The SSID to which a volume for the local storage system belongsMCU SSID
The serial number of the remote storage systemRCU S/N
The SSID to which a volume for the remote storage system belongsRCU SSID
The port name of the local storage systemMCU Port
The port name of the remote storage systemRCU Port
The CU number of the remote storage systemRCU CU
Config Command (Mainframe system) 287
