HP XP7 Audit Log User and Reference Guide (H6F56-96001)

TERM PAIR
Example
08xx,YYYY/MM/DD,HH:MM:SS.xxx, 00:00,In-band MF,uid=user-name,,,
[Config Command],,,Accept,
from=xxxx:xxxx:xxxx:xxxx:xxxx:xxxx:xxxx:xxxx,,Seq.=xxxxxxxxxx
+Command=TERM PAIR
++P-VOL(LDEV)=0xAA,S-VOL(LDEV)=0xBB,MCU S/N=12345,
MCU SSID=0x1234,RCU S/N=23456,RCU SSID=0x2345
+0000010200000000 0000000000000000
+0123456789ABCDEF 0123456789ABCDEF 0123456789ABCDEF,(snip)
Detailed Information
DescriptionParameter
The command nameCommand
The LDEV number of the primary volumeP-VOL(LDEV)
The LDEV number of the secondary volumeS-VOL(LDEV)
The serial number of the local storage systemMCU S/N
The SSID to which a volume for the local storage system belongsMCU SSID
The serial number of the remote storage systemRCU S/N
The SSID to which a volume for the remote storage system belongsRCU SSID
Indicates the 16 byte parameter added in the storage system and the command
parameter in binary format
Command parameter
FC-SP
08xx,YYYY/MM/DD,HH:MM:SS.xxx, 00:00,In-band OPEN,<Host>,,,
[FC-SP],,,Normal end,from=xxxxxxxxxxxxxxxx,,Seq.=xxxxxxxxxx
• In-band OPEN
The host is an open-system host.
• from=xxxxxxxxxxxxxx
WWN of the host that sent the command.
User Auth
08xx,YYYY/MM/DD,HH:MM:SS.xxx, 00:00,In-band OPEN,uid=user-name,
195,,[User Auth],Login,,Normal end,from=xxxxxxxxxxxxxxxx,
AP=0xXXXX,Seq.=xxxxxxxxxx
08xx,YYYY/MM/DD,HH:MM:SS.xxx, 00:00,In-band OPEN,uid=user-name,
195,,[User Auth],Logout,,Normal end,from=xxxxxxxxxxxxxxxx,
AP=0xXXXX,Seq.=xxxxxxxxxx
• In-band OPEN
The host is an open-system host.
• from=xxxxxxxxxxxxxx
WWN of the host that sent the command.
• AP=0xXXXX
Internal ID used by the host and the storage system.
FC-SP 289
