Table 36 Performance Monitor

Audit Log OutputGUI operation

Operation NameFunction NameDescriptionSubmenu

Edit Monitoring SWPerf MonStarting/stopping monitoringEdit Monitoring Switch

Edit CU Monitor ModePerf MonSetting target CUs for

monitoring

Edit CU Monitor Mode

Edit WWN MonitorModePerf MonSetting target WWNs for

monitoring

Edit WWN Monitor Mode

Edit WWN MonitorModePerf MonAdding new WWNs for

monitoring

Add New Monitored

WWNs

Edit WWNPerf MonEditing WWNEdit WWN

Delete Unused WWNsPerf MonDeleting WWNs from

monitoring targets

Delete Unused WWNs

Edit WWN MonitorModePerf MonAdding monitored WWN to

a port

Add to Ports

Set All Prio Port

1, 2

Perf CtlAll ThresholdsPerformance Control (Port)

Set Ctrl Kind

Set Prio Port

1, 2

Perf CtlSetting priority for ports

(Attribute / Threshold /

Upper)

Set All Prio Port

Default Set

1, 2

Perf CtlInitializing

Set Ctrl KindPerf CtlCurrent Control Status (Port

Control)

Clear PFC Info

Perf CtlClearing port settings due to

removing port controllers

Set All Prio WWN

1, 2

Perf CtlAll ThresholdsPerformance Control

(WWN)

Set Prio WWN

1, 2

Perf CtlSetting priority for WWNs

(Attribute / Upper)

Set All Prio WWN

Update WWN

1, 2

Perf CtlChanging WWN and PFC

name

Set All Prio WWN

Set Ctrl Kind

1, 2

Perf CtlCurrent Control Status (WWN

Control)

Update Port WWN

1, 2

Perf CtlAdding WWN

Update Port WWN

1, 2

Perf CtlDeleting WWN

Default Set

Perf CtlInitializing

Update PFCGrp

1, 2

Perf CtlAdding WWN (to PFC group)

Update PFCGrp

1, 2

Perf CtlDeleting WWN (from PFC

group)

Update PFCGrp

1, 2

Perf CtlAdding PFC group and

WWN

Set All Prio WWN

Update PFCGrp

1, 2

Perf CtlDeleting PFC group

PFCGrp Del/Chg

Set All Prio WWN

Using Reports menu 303
