HP XP7 Audit Log User and Reference Guide (H6F56-96001)

Basic Information for Example 1
DescriptionParameter
Indicates that the External Authentication server is not usedDisable
Example 2
08xx,YYYY/MM/DD,HH:MM:SS.xxx, 00:00,RMI AP,uid=user-name,1,
Task Name,[ACM],Setup Server,LDAP,Normal end,
from=xxxx:xxxx:xxxx:xxxx:xxxx:xxxx:xxxx:xxxx,,Seq.=xxxxxxxxxx
+{Certificate File Name,DNS Lookup,Authentication Protocol,
External User Group Mapping,Primary Host Name,
Primary Port Number,Domain Name,User Name Attribute,Base DN,
Search User's DN,Timeout,Retry Interval,Number of Retries}=
-{CFFILE,Disable,STARTTLS,Enable,
-examplehost,389,example1.com,sAMAccountName,
-dc=example2 dc=com,example3.com,10,1,3}
++{Secondary Server,Secondary Host Name,Secondary Port Number}=
{Enable,example4.com,389}
+Num. of Servers=1
Basic Information for Example 2
DescriptionParameter
Indicates that the LDAP server is used as the External Authentication serverLDAP
Detailed Information for Example 2
DescriptionItem
Indicates the name of certificate fileCertificate File Name
Indicates whether to search the LDAP server using the information registered in the SRV
records in the DNS server
DNS Lookup
Enable: Performs the search using information registered in the SRV records in the DNS
server
Disable: Performs the search using the host name and the port number
Indicates the LDAP protocol (LDAP over SSL/TLS or STARTTLS) to useAuthentication Protocol
Indicates whether to connect an authentication server to an authorization serverExternal User Group
Mapping
Enable: Connects an authentication server to an authorization server
Disable: Does not connect an authentication server to an authorization server
Indicates the host name of the LDAP serverPrimary Host Name
Indicates the port number of the LDAP serverPrimary Port Number
Indicates the domain name that the LDAP server managesDomain Name
Indicates the attribute name to identify a userUser Name Attribute
Indicates the Base DN (Distinguished Name) for searching for users to authenticateBase DN
Commas that are input by user are indicated with spaces
Indicates the DN of the user for searchingSearch User's DN
Indicates the number of seconds before connection to the LDAP server times outTimeout
Indicates the retry interval in seconds when the connection to the LDAP server failsRetry Interval
Indicates the retry times when the connection to the LDAP server failsNumber of Retries
ACM Descriptions 53
