{3D,Target,Auto,0x00:0x00-0x00:0xFE},
{5D,Target,Auto,0x00:0x00-0x00:0xFE},
{7D,Target,Auto,0x00:0x00-0x00:0xFE}],
Num. of Ports=8
+{CHA,Kind}={CHA-1PE,16M8 (Mfibre)},
++{Port,HTP/FNP,CU Number,Emulation}
=[{1E,HTP,0x00:0x00-0x00:0x3F,H-6591-C3},
{3E,HTP,0x00:0x00-0x00:0x3F,H-6591-C3},
{5E,HTP,0x00:0x00-0x00:0x3F,H-6591-C3},
{7E,HTP,0x00:0x00-0x00:0x3F,H-6591-C3},
{1F,HTP,0x00:0x00-0x00:0x3F,H-6591-C3},
{3F,HTP,0x00:0x00-0x00:0x3F,H-6591-C3},
{5F,HTP,0x00:0x00-0x00:0x3F,H-6591-C3},
{7F,HTP,0x00:0x00-0x00:0x3F,H-6591-C3}],
Num. of Ports=8
+{CHA,Kind}={CHA-2PD,16FC8(Fibre )},
++{Port,Initiator/Target,Channel Speed,CU Number}
=[{2C,Target,Auto,0x00:0x00-0x00:0xFE},
{4C,Target,Auto,0x00:0x00-0x00:0xFE},
{6C,Target,Auto,0x00:0x00-0x00:0xFE},
{8C,Target,Auto,0x00:0x00-0x00:0xFE},
{2D,Target,Auto,0x00:0x00-0x00:0xFE},
{4D,Target,Auto,0x00:0x00-0x00:0xFE},
{6D,Target,Auto,0x00:0x00-0x00:0xFE},
{8D,Target,Auto,0x00:0x00-0x00:0xFE}],
Num. of Ports=8
+{CHA,Kind}={CHA-2PE,16M8 (Mfibre)},
++{Port,HTP/FNP,CU Number,Emulation}
=[{2E,HTP,0x00:0x00-0x00:0x3F,H-6591-C3},
{4E,HTP,0x00:0x00-0x00:0x3F,H-6591-C3},
{6E,HTP,0x00:0x00-0x00:0x3F,H-6591-C3},
{8E,HTP,0x00:0x00-0x00:0x3F,H-6591-C3},
{2F,HTP,0x00:0x00-0x00:0x3F,H-6591-C3},
{4F,HTP,0x00:0x00-0x00:0x3F,H-6591-C3},
{6F,HTP,0x00:0x00-0x00:0x3F,H-6591-C3},
{8F,HTP,0x00:0x00-0x00:0x3F,H-6591-C3}],
Num. of Ports=8
+Num. of CHAs=4
Detailed Information for Example 1
DescriptionItem
The channel adapter (CHA) mounting locationCHA
The kind of PCB mountedKind
The mounting location of the portPort
The type of Initiator or TargetInitiator/Target
The channel speed is indicated for open systemsChannel Speed
2: 2 Gbps, 4: 4 Gbps, 8: 8 Gbps, 16: 16 Gbps, Auto: Auto mode.
Indicates the range of the CU number that the port belongsCU Number
The number of portsNum. of Ports
The HTP or FNP is indicated for FICONHTP/FNP
The emulation type is indicated for mainframe systemsEmulation
The number of Channel Adapter (CHA)sNum. of CHAs
