Example 2: installing additional DKAs
08xx,YYYY/MM/DD,HH:MM:SS.xxx, 00:00,SVP,uid=user-name,1,,
[Install],Install,,Normal end,
from=xxxx:xxxx:xxxx:xxxx:xxxx:xxxx:xxxx:xxxx,,Seq.=xxxxxxxxxx
+{DKA,Kind}=[{DKA-1PB,DKA (4Port)},{DKA-1PH,DKA (4Port)},
{DKA-2PB,DKA (4Port)},{DKA-2PH,DKA (4Port}],Num. of DKAs=4
Detailed Information for Example 2
DescriptionItem
The Disk Adapter mounting locationDKA
The type of Disk AdapterKind
The number of Disk AdaptersNum. of DKAs
Note: Only the changed items are output.
Example 3: installing additional ECC Groups or LDEVs
08xx,YYYY/MM/DD,HH:MM:SS.xxx, 00:00,SVP,uid=user-name,1,,
[Install],Install,,Normal end,
from=xxxx:xxxx:xxxx:xxxx:xxxx:xxxx:xxxx:xxxx,,Seq.=xxxxxxxxxx
+{DKU,Kind}
=[{DKU-01,3.5" DKU},{DKU-02,FBX}],Num. of DKUs=2
+{PG,RAID Level,Drive Type,Emulation,Concatenation,Encryption}
={1-1,RAID5 (3D+1P),DKR5D-J900SS,OPEN-V,-,Disable},
++{LDKC:CU:LDEV,Emulation,Size,Unit,SSID,MPB}
=[{0x00:0x00:0x00,OPEN-V,5066268672,LBA,0x1111,MPB-1MA}],
Num. of LDEVs=1
+{PG,RAID Level,Drive Type,Emulation,Concatenation,Encryption}
={1-2,RAID5 (3D+1P),DKR5D-J900SS,OPEN-V,-,Disable},
++{LDKC:CU:LDEV,Emulation,Size,Unit,SSID,MPB}
=[{0x00:0x00:0x01,OPEN-V,5066268672,LBA,0x1111,Auto}],
Num. of LDEVs=1
+Num. of PGs=2
+{B4,SPARE,Drive Type}=[{1,1,DKR5D-J900SS}],Num. of SPAREs=1
Basic Information for Example 3
DescriptionParameter
The window that shows the progress of LDEV formatting has closed.Progress Close
Quick Format is selected.Quick Format
The window that shows the progress of preparing for Quick Format has closed.Quick Format Close
Note: No parameter is output for any case other than those described in this table.
Detailed Information for Example 3
Only the changed items are output. The detailed information on the recovery process is not output
when the setting at the time of installation before the recovery process is complete. However, when
the setting is not complete, the setting on the recovery process is output as the detailed information.
DescriptionItem
The mounting location of Disk UnitDKU
The type of DKUKind
The number of Disk UnitsNum. of DKUs
