HP XP7 Audit Log User and Reference Guide (H6F56-96001)

DescriptionItem
The B4 numberB4
The spare drive numberSPARE
The number of spare drivesNum. of SPAREs
Example 4: removing a cache memory module
08xx,YYYY/MM/DD,HH:MM:SS.xxx, 00:00,SVP,uid=user-name,1,,
[Install],Remove,,Normal end,
from=xxxx:xxxx:xxxx:xxxx:xxxx:xxxx:xxxx:xxxx,,Seq.=xxxxxxxxxx
+{CM,CMG,Size}
=[{1CA/2CA,CM16G x 2,65536},{1CB/2CB,CM16G x 2,65536},
{1CE/2CG,CM16G x 2,65536},{1CF/2CH,CM16G x 2,65536}],Num. of CMs=4
+{BKM,Type,Size}=[{1BA/2BA,BKML,BMM128 x 2(400GB)},
{1BB/2BB,BKML,BMM128 x 2(400GB)},{1BC/2BC,BKML,BMM128 x 2(400GB)},
{1BD/2BD,BKML,BMM128 x 2(400GB)}],Num. of BKMs=4
+DCR available size=1024
+{CLPR,Cache size,DCR size,Extent Number}
=[{CLPR0,217088,3072,15384}],Num. of CLPRs=1
+PP Flag=[(64KLDEV, SI/VM Extension, TPF),(TC/UR)],
Num. of PP Flags=2
+Max Number of CUs=64
Detailed Information for Example 4
DescriptionItem
The mounting location of the PCB for cache memoryCM
The capacity of the CMGCMG
The capacity of the cache memorySize
The number of cache memoriesNum. of CMs
The mounting location for BKMBKM
The type of BKMType
The size of CFMSize
The number of BKMsNum. of BKMs
The capacity of the Cache ResidencyDCR available size
The CLPR numberCLPR
The capacity of the cache memory allocated to CLPRCache size
The capacity of the Cache Residency allocated to CLPRDCR size
The number of extents allocated to CLPRExtent Number
The number of CLPRsNum. of CLPRs
The flag of the program productPP Flag
The number of program product flagsNum. of PP Flags
The maximum number of CUsMax Number of CUs
Note: Only the changed items are output.
Example 5: removing MPB
08xx,YYYY/MM/DD,HH:MM:SS.xxx, 00:00,SVP,uid=user-name,1,,
[Install],Remove,,Normal end,
92 Audit log examples
