DescriptionItem
The connecting mode of the Fabric switch selectedConnection
FC-AL: FC-AL is selected, P-to-P: P-to-P is selected
The number of ports where the topology of Fibre Channel is setNum. of Ports
[Install] Set Host Mode
Example
08xx,YYYY/MM/DD,HH:MM:SS.xxx, 00:00,SVP,uid=user-name,1,,
[Install],Set Host Mode,,Normal end,
from=xxxx:xxxx:xxxx:xxxx:xxxx:xxxx:xxxx:xxxx,,Seq.=xxxxxxxxxx
+{Port,HostGrpID,Mode,Option[0:31],Option[32:63],Option[64:95],
Option[96:127]}
=[{XX,0xXXX,0x00,0xXXXXXXXX,0xXXXXXXXX,0xXXXXXXXX,0xXXXXXXXX},
{XX,0xXXX,0x4F,0xXXXXXXXX,0xXXXXXXXX,0xXXXXXXXX,0xXXXXXXXX}],
Num. of Host Groups=2
Detailed Information
DescriptionItem
The name of the port to which the host group belongsPort
The host group numberHostGrpID
The host mode set. Please see the HP XP7 Provisioning for Open Systems User Guide for the
meaning of the host mode number
Mode
The specified host mode option. 128 host mode options from 0 to 127 are output in groups
of 32 options. Please see Table 14 (page 140) to Table 17 (page 141) for the relation of output
values and host mode option.
Option[0:31]
Option[32:63]
Option[64:95]
Option[96:127]
Please see the HP XP7 Provisioning for Open Systems User Guide for the meaning of the
host mode number.
The number of host groups that the host mode setting is changedNum. of Host Groups
[Install] Set IP Address
Example
08xx,YYYY/MM/DD,HH:MM:SS.xxx, 00:00,SVP,uid=user-name,1,,
[Install],Set IP Address,SVP and DKC,Normal end,
from=xxxx:xxxx:xxxx:xxxx:xxxx:xxxx:xxxx:xxxx,,Seq.=xxxxxxxxxx
+{IPAddress,Subnet Mask}={(123.456.789.123),(255.255.255.255)}
+Use Duplex=Valid
+Svp Kind=Master SVP
+IPv4=Valid
+IPv6=Valid
+{M-SVP IPv4(IPAddress,Subnet Mask),
IPv6(IPAddress,Subnet Prefix length)}
={((111.222.333.444),(255.255.255.255)),
((1111:2222:3333:4444:5555:6666:7777:8888),(64))}
+{S-SVP IPv4(IPAddress,Subnet Mask),
IPv6(IPAddress,Subnet Prefix length)}
={((555.666.777.888),(255.255.255.255)),
((9999:AAAA:BBBB:CCCC:DDDD:EEEE:FFFF:0000),(64))}
